SDO HMI 2014-12-05 13:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 11.43 | 0.00 | 5.91 | -15.90 | 36.64 | -3.86 | 166.59 | 0.2916 | -221.0 | -309.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-12-05 13:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.11 | 0.00 | 0.57 | -16.19 | 42.49 | 1.99 | 186.69 | 0.2876 | 880.0 | 694.0 | |
| 0.00 | 1.02 | 0.00 | 0.54 | -19.54 | 40.18 | -0.33 | 179.09 | 0.3415 | 671.0 | 571.1 | |
| 0.00 | 1.11 | 0.00 | 0.58 | -19.51 | 37.61 | -2.90 | 172.01 | 0.3443 | 745.0 | 523.6 | |
| 0.00 | 1.11 | 0.00 | 0.57 | -14.25 | 36.84 | -3.67 | 166.17 | 0.2604 | -806.0 | -709.5 | |
| 0.00 | 3.58 | 0.00 | 1.84 | -14.58 | 35.52 | -4.99 | 161.90 | 0.2720 | -948.0 | -770.4 | |
| 0.00 | 1.02 | 0.00 | 0.53 | -15.13 | 34.64 | -5.86 | 159.71 | 0.2856 | -811.0 | -707.5 | |
| 0.00 | 1.88 | 0.00 | 0.97 | -15.59 | 34.54 | -5.97 | 159.95 | 0.2934 | -726.0 | -457.7 | |
| 0.00 | 0.60 | 0.00 | 0.31 | -15.41 | 34.23 | -6.27 | 158.79 | 0.2923 | -773.0 | -645.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
