SDO HMI 2014-12-06 03:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 162.13 | 927.25 | 142.94 | 810.21 | -19.45 | 85.85 | 53.07 | 245.97 | 0.8271 | 604.8 | 286.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-12-06 03:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.51 | 1.71 | 0.51 | 1.69 | -20.16 | 90.52 | 57.74 | 246.40 | 0.8683 | -601.2 | -478.9 | |
| 0.00 | 1.19 | 0.00 | 1.14 | -19.59 | 89.10 | 56.31 | 246.71 | 0.8556 | -323.0 | -292.4 | |
| 32.68 | 854.96 | 29.91 | 752.88 | -18.73 | 87.82 | 55.04 | 247.37 | 0.8430 | 597.0 | 316.7 | |
| 6.91 | -3.00 | 6.32 | -3.00 | -19.26 | 87.65 | 54.86 | 246.71 | 0.8426 | 401.4 | 999999 | |
| 19.54 | -3.00 | 17.60 | -3.00 | -18.95 | 87.11 | 54.33 | 246.94 | 0.8373 | 849.9 | 999999 | |
| 19.71 | -3.00 | 17.42 | -3.00 | -19.01 | 86.34 | 53.55 | 246.66 | 0.8305 | 891.1 | 999999 | |
| 37.89 | -3.00 | 32.97 | -3.00 | -19.44 | 85.54 | 52.76 | 245.93 | 0.8244 | 1022.1 | 999999 | |
| 0.00 | 1.62 | 0.00 | 1.45 | -21.50 | 86.15 | 53.36 | 243.70 | 0.8350 | -337.0 | -185.7 | |
| 0.26 | -3.00 | 0.22 | -3.00 | -20.48 | 85.10 | 52.32 | 244.58 | 0.8231 | 543.3 | 999999 | |
| 35.67 | -3.00 | 30.75 | -3.00 | -20.19 | 84.91 | 52.13 | 244.86 | 0.8206 | 1063.5 | 999999 | |
| 0.00 | 0.77 | 0.00 | 0.64 | -18.05 | 83.72 | 50.94 | 247.05 | 0.8040 | 255.0 | 252.0 | |
| 0.00 | 2.22 | 0.00 | 1.82 | -17.99 | 83.40 | 50.62 | 247.03 | 0.8007 | -250.0 | -74.7 | |
| 2.39 | -3.00 | 2.05 | -3.00 | -21.49 | 84.25 | 51.47 | 243.13 | 0.8183 | -271.4 | 999999 | |
| 0.00 | 3.24 | 0.00 | 2.67 | -19.02 | 83.13 | 50.35 | 245.71 | 0.8009 | 469.0 | 496.8 | |
| 1.96 | -3.00 | 1.65 | -3.00 | -20.79 | 83.66 | 50.88 | 243.76 | 0.8109 | 945.1 | 999999 | |
| 0.00 | 1.19 | 0.00 | 0.97 | -18.58 | 82.71 | 49.92 | 246.11 | 0.7956 | -264.0 | -164.9 | |
| 0.00 | 11.01 | 0.00 | 9.05 | -19.39 | 82.94 | 50.16 | 245.19 | 0.8001 | 362.0 | 343.4 | |
| 0.00 | 0.68 | 0.00 | 0.55 | -18.42 | 82.55 | 49.76 | 246.25 | 0.7936 | -18.0 | -136.9 | |
| 0.00 | 0.77 | 0.00 | 0.65 | -21.64 | 83.82 | 51.04 | 242.80 | 0.8148 | 391.0 | 335.0 | |
| 0.00 | 0.60 | 0.00 | 0.49 | -20.30 | 82.35 | 49.57 | 243.90 | 0.7972 | -98.0 | -104.7 | |
| 0.00 | 0.60 | 0.00 | 0.49 | -21.22 | 82.32 | 49.54 | 242.79 | 0.7998 | 499.0 | 477.9 | |
| 0.00 | 2.22 | 0.00 | 1.81 | -21.03 | 82.14 | 49.35 | 242.95 | 0.7974 | 701.0 | 593.0 | |
| 0.00 | 1.02 | 0.00 | 0.85 | -22.31 | 82.69 | 49.90 | 241.63 | 0.8066 | 553.0 | 404.8 | |
| 0.00 | 0.77 | 0.00 | 0.63 | -22.56 | 81.97 | 49.18 | 241.07 | 0.8008 | 712.0 | 603.6 | |
| 0.00 | 0.94 | 0.00 | 0.73 | -19.63 | 80.22 | 47.43 | 243.97 | 0.7743 | -558.0 | -421.5 | |
| 0.00 | 0.85 | 0.00 | 0.67 | -20.39 | 80.38 | 47.60 | 243.10 | 0.7784 | -407.0 | -367.8 | |
| 1.45 | 4.27 | 1.14 | 3.34 | -20.55 | 80.21 | 47.42 | 242.84 | 0.7773 | -625.1 | -460.0 | |
| 0.00 | 0.94 | 0.00 | 0.73 | -20.64 | 79.97 | 47.18 | 242.63 | 0.7753 | -517.0 | -393.9 | |
| 0.00 | 0.94 | 0.00 | 0.72 | -19.60 | 79.46 | 46.68 | 243.73 | 0.7666 | -378.0 | -380.9 | |
| 0.00 | 3.67 | 0.00 | 2.83 | -20.35 | 79.43 | 46.65 | 242.78 | 0.7690 | -724.0 | -612.7 | |
| 0.00 | 1.71 | 0.00 | 1.32 | -20.79 | 79.43 | 46.64 | 242.23 | 0.7705 | 708.0 | 586.3 | |
| 0.00 | 2.56 | 0.00 | 1.99 | -21.02 | 79.52 | 46.73 | 242.00 | 0.7722 | 654.0 | 568.3 | |
| 0.00 | 0.60 | 0.00 | 0.46 | -21.40 | 79.16 | 46.38 | 241.39 | 0.7701 | 438.0 | 421.1 | |
| 2.56 | 8.28 | 1.96 | 6.34 | -21.36 | 78.64 | 45.86 | 241.22 | 0.7649 | 110.6 | -23.1 | |
| 0.00 | 1.45 | 0.00 | 1.08 | -19.08 | 77.70 | 44.92 | 243.69 | 0.7467 | -707.0 | -515.2 | |
| 0.00 | 1.02 | 0.00 | 0.77 | -20.44 | 77.74 | 44.96 | 241.99 | 0.7523 | -664.0 | -507.2 | |
| 0.00 | 1.28 | 0.00 | 0.94 | -19.27 | 76.88 | 44.10 | 243.12 | 0.7389 | -702.0 | -589.7 | |
| 0.00 | 0.60 | 0.00 | 0.46 | -22.80 | 78.19 | 45.40 | 239.26 | 0.7660 | -579.0 | -519.6 | |
| 0.60 | 1.96 | 0.44 | 1.45 | -20.05 | 76.98 | 44.20 | 242.16 | 0.7429 | -739.1 | -604.1 | |
| 0.00 | 1.28 | 0.00 | 0.93 | -19.30 | 76.67 | 43.89 | 242.99 | 0.7368 | -876.0 | -721.9 | |
| 0.00 | 0.94 | 0.00 | 0.69 | -19.68 | 76.67 | 43.89 | 242.51 | 0.7382 | -660.0 | -543.5 | |
| 0.00 | 1.19 | 0.00 | 0.88 | -20.37 | 76.83 | 44.04 | 241.69 | 0.7426 | -591.0 | -522.2 | |
| 0.00 | 1.37 | 0.00 | 1.04 | -22.63 | 77.62 | 44.83 | 239.21 | 0.7598 | -613.0 | -457.1 | |
| 0.00 | 0.60 | 0.00 | 0.44 | -21.13 | 76.89 | 44.10 | 240.76 | 0.7463 | -604.0 | -508.6 | |
| 0.00 | 1.02 | 0.00 | 0.75 | -20.65 | 76.62 | 43.84 | 241.24 | 0.7417 | -608.0 | -527.3 | |
| 0.00 | 0.68 | 0.00 | 0.51 | -21.58 | 76.88 | 44.09 | 240.19 | 0.7481 | -488.0 | -421.6 | |
| 0.00 | 1.45 | 0.00 | 1.08 | -21.73 | 76.85 | 44.07 | 239.98 | 0.7485 | -360.0 | -353.2 | |
| 0.00 | 0.77 | 0.00 | 0.59 | -24.83 | 77.44 | 44.65 | 236.46 | 0.7676 | -541.0 | -444.6 | |
| 0.00 | 0.94 | 0.00 | 0.67 | -19.83 | 75.30 | 42.51 | 241.70 | 0.7243 | -560.0 | -506.6 | |
| 0.00 | 1.37 | 0.00 | 1.02 | -23.47 | 76.57 | 43.78 | 237.71 | 0.7532 | -356.0 | -348.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
