SDO HMI 2014-12-06 05:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 156.17 | 929.16 | 141.50 | 832.41 | -19.43 | 85.81 | 54.12 | 246.29 | 0.8363 | 643.3 | 271.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-12-06 05:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.34 | 1.54 | 0.35 | 1.57 | -20.14 | 90.45 | 58.76 | 246.66 | 0.8763 | -347.8 | -344.0 | |
| 47.28 | 864.43 | 44.21 | 780.40 | -18.81 | 87.55 | 55.86 | 247.49 | 0.8502 | 728.8 | 296.2 | |
| 0.85 | -2.00 | 0.81 | -2.00 | -19.28 | 87.79 | 56.10 | 247.01 | 0.8532 | 200.2 | 999999 | |
| 1.79 | -2.00 | 1.68 | -2.00 | -19.22 | 87.65 | 55.96 | 247.05 | 0.8518 | 432.4 | 999999 | |
| 5.89 | -2.00 | 5.45 | -2.00 | -18.49 | 87.23 | 55.54 | 247.78 | 0.8468 | 730.8 | 999999 | |
| 0.26 | -2.00 | 0.23 | -2.00 | -18.43 | 86.76 | 55.06 | 247.74 | 0.8426 | 757.3 | 999999 | |
| 17.84 | -2.00 | 16.15 | -2.00 | -18.99 | 86.26 | 54.57 | 246.96 | 0.8394 | 952.0 | 999999 | |
| 0.00 | 1.02 | 0.00 | 0.90 | -17.77 | 85.48 | 53.79 | 248.19 | 0.8298 | 544.0 | 445.1 | |
| 22.36 | -2.00 | 20.04 | -2.00 | -19.30 | 85.71 | 54.02 | 246.45 | 0.8353 | 962.8 | 999999 | |
| 1.79 | -2.00 | 1.61 | -2.00 | -19.84 | 85.87 | 54.18 | 245.87 | 0.8379 | 92.6 | 999999 | |
| 53.00 | -2.00 | 46.87 | -2.00 | -20.02 | 85.00 | 53.31 | 245.42 | 0.8307 | 1109.4 | 999999 | |
| 0.00 | 3.41 | 0.00 | 2.90 | -18.01 | 83.82 | 52.13 | 247.46 | 0.8151 | 524.0 | 319.1 | |
| 0.00 | 2.13 | 0.00 | 1.82 | -18.41 | 83.84 | 52.15 | 246.98 | 0.8163 | 400.0 | 354.3 | |
| 0.00 | 1.02 | 0.00 | 0.92 | -21.73 | 85.40 | 53.71 | 243.54 | 0.8385 | 77.0 | 150.2 | |
| 0.00 | 2.65 | 0.00 | 2.22 | -17.88 | 83.37 | 51.68 | 247.48 | 0.8105 | -274.0 | -85.8 | |
| 1.79 | -2.00 | 1.57 | -2.00 | -21.12 | 84.23 | 52.54 | 243.90 | 0.8267 | 808.3 | 999999 | |
| 0.94 | -2.00 | 0.82 | -2.00 | -21.54 | 84.23 | 52.54 | 243.42 | 0.8278 | -255.7 | 999999 | |
| 1.19 | -2.00 | 1.04 | -2.00 | -21.15 | 83.88 | 52.19 | 243.76 | 0.8237 | 633.8 | 999999 | |
| 0.00 | 0.94 | 0.00 | 0.78 | -18.47 | 82.61 | 50.92 | 246.55 | 0.8048 | -188.0 | -68.2 | |
| 0.00 | 2.47 | 0.00 | 2.07 | -19.13 | 82.84 | 51.14 | 245.83 | 0.8087 | 598.0 | 394.7 | |
| 0.00 | 1.02 | 0.00 | 0.85 | -18.66 | 82.64 | 50.94 | 246.34 | 0.8055 | 164.0 | 97.2 | |
| 0.00 | 1.02 | 0.00 | 0.85 | -18.81 | 82.50 | 50.81 | 246.11 | 0.8047 | -346.0 | -266.5 | |
| 0.00 | 0.77 | 0.00 | 0.64 | -21.11 | 82.13 | 50.44 | 243.24 | 0.8077 | 528.0 | 515.4 | |
| 0.00 | 2.47 | 0.00 | 2.07 | -21.33 | 82.18 | 50.49 | 242.99 | 0.8089 | 525.0 | 441.9 | |
| 0.00 | 1.11 | 0.00 | 0.94 | -22.16 | 82.28 | 50.59 | 242.05 | 0.8123 | 363.0 | 334.9 | |
| 0.00 | 0.94 | 0.00 | 0.77 | -20.51 | 81.45 | 49.76 | 243.74 | 0.7996 | 252.0 | 331.0 | |
| 0.00 | 0.85 | 0.00 | 0.72 | -22.61 | 81.80 | 50.11 | 241.35 | 0.8093 | 434.0 | 498.7 | |
| 0.00 | 4.95 | 0.00 | 3.96 | -20.59 | 80.14 | 48.44 | 243.17 | 0.7873 | -723.0 | -475.2 | |
| 0.00 | 0.51 | 0.00 | 0.40 | -19.58 | 79.58 | 47.89 | 244.21 | 0.7786 | -437.0 | -413.5 | |
| 0.00 | 3.16 | 0.00 | 2.49 | -20.37 | 79.38 | 47.69 | 243.17 | 0.7792 | -744.0 | -598.4 | |
| 0.00 | 1.28 | 0.00 | 0.99 | -19.55 | 78.87 | 47.17 | 243.99 | 0.7714 | -527.0 | -434.4 | |
| 0.00 | 4.27 | 0.00 | 3.37 | -20.94 | 79.33 | 47.64 | 242.45 | 0.7807 | 589.0 | 546.5 | |
| 0.85 | 9.39 | 0.67 | 7.32 | -21.38 | 78.72 | 47.03 | 241.68 | 0.7763 | -113.4 | 283.0 | |
| 0.00 | 0.43 | 0.00 | 0.33 | -21.63 | 78.64 | 46.95 | 241.34 | 0.7764 | -568.0 | -516.4 | |
| 0.00 | 0.85 | 0.00 | 0.65 | -20.36 | 77.85 | 46.15 | 242.59 | 0.7640 | -540.0 | -468.1 | |
| 0.00 | 1.19 | 0.00 | 0.94 | -22.43 | 78.56 | 46.87 | 240.34 | 0.7787 | -412.0 | -278.2 | |
| 0.00 | 1.45 | 0.00 | 1.08 | -19.25 | 76.90 | 45.20 | 243.60 | 0.7503 | -588.0 | -435.0 | |
| 0.00 | 1.02 | 0.00 | 0.77 | -20.04 | 76.95 | 45.26 | 242.63 | 0.7538 | -544.0 | -589.7 | |
| 0.00 | 1.02 | 0.00 | 0.76 | -19.28 | 76.64 | 44.95 | 243.46 | 0.7477 | -725.0 | -639.7 | |
| 0.00 | 1.28 | 0.00 | 0.96 | -20.36 | 76.85 | 45.16 | 242.19 | 0.7539 | -696.0 | -599.1 | |
| 0.00 | 0.68 | 0.00 | 0.51 | -19.69 | 76.61 | 44.91 | 242.93 | 0.7489 | -551.0 | -456.8 | |
| 0.00 | 1.02 | 0.00 | 0.79 | -22.59 | 77.61 | 45.92 | 239.75 | 0.7701 | -383.0 | -373.3 | |
| 0.00 | 0.34 | 0.00 | 0.26 | -21.15 | 76.97 | 45.28 | 241.25 | 0.7582 | -410.0 | -463.2 | |
| 0.00 | 1.19 | 0.00 | 0.90 | -20.61 | 76.63 | 44.94 | 241.78 | 0.7526 | -441.0 | -443.9 | |
| 0.00 | 0.60 | 0.00 | 0.45 | -21.34 | 76.59 | 44.90 | 240.86 | 0.7551 | -621.0 | -559.3 | |
| 0.00 | 0.43 | 0.00 | 0.32 | -21.08 | 75.87 | 44.18 | 240.87 | 0.7468 | -648.0 | -556.2 | |
| 0.00 | 0.34 | 0.00 | 0.27 | -25.08 | 77.53 | 45.84 | 236.72 | 0.7796 | -549.0 | -470.8 | |
| 0.00 | 1.19 | 0.00 | 0.94 | -24.85 | 77.42 | 45.73 | 236.94 | 0.7776 | -402.0 | -358.7 | |
| 0.00 | 0.51 | 0.00 | 0.38 | -21.01 | 75.67 | 43.98 | 240.86 | 0.7445 | -604.0 | -477.2 | |
| 0.00 | 0.68 | 0.00 | 0.52 | -23.52 | 76.58 | 44.89 | 238.17 | 0.7640 | -340.0 | -346.2 | |
| 0.00 | 1.54 | 0.00 | 1.12 | -20.22 | 74.90 | 43.21 | 241.53 | 0.7333 | -121.0 | -220.7 | |
| 0.00 | 0.51 | 0.00 | 0.37 | -20.82 | 74.25 | 42.55 | 240.46 | 0.7290 | -576.0 | -495.0 | |
| 0.00 | 1.54 | 0.00 | 1.14 | -23.64 | 74.70 | 43.01 | 237.14 | 0.7463 | -643.0 | -446.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
