SDO HMI 2014-12-06 15:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 145.50 | 759.49 | 151.43 | 788.67 | -19.54 | 85.62 | 59.40 | 247.47 | 0.8799 | 668.2 | 215.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-12-06 15:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.60 | 0.00 | 0.66 | -17.52 | 87.96 | 61.74 | 250.19 | 0.8947 | 256.0 | 234.1 | |
| 0.94 | 733.31 | 1.03 | 765.53 | -18.32 | 87.79 | 61.56 | 249.27 | 0.8945 | 348.4 | 229.9 | |
| 32.84 | -2.00 | 35.78 | -2.00 | -18.76 | 87.47 | 61.24 | 248.73 | 0.8927 | 638.8 | 999999 | |
| 4.26 | -2.00 | 4.68 | -2.00 | -19.17 | 87.66 | 61.43 | 248.31 | 0.8947 | 350.8 | 999999 | |
| 19.10 | -2.00 | 19.98 | -2.00 | -18.85 | 86.11 | 59.89 | 248.37 | 0.8827 | 911.5 | 999999 | |
| 23.80 | -2.00 | 24.71 | -2.00 | -19.32 | 85.76 | 59.54 | 247.77 | 0.8807 | 759.2 | 999999 | |
| 58.00 | -2.00 | 58.65 | -2.00 | -20.10 | 84.70 | 58.47 | 246.67 | 0.8738 | 953.2 | 999999 | |
| 5.71 | -2.00 | 5.78 | -2.00 | -21.39 | 84.40 | 58.18 | 245.15 | 0.8739 | 702.7 | 999999 | |
| 0.00 | 0.68 | 0.00 | 0.65 | -19.02 | 82.57 | 56.35 | 247.39 | 0.8546 | -217.0 | 7.6 | |
| 0.34 | 1.02 | 0.34 | 1.03 | -21.68 | 83.98 | 57.76 | 244.73 | 0.8712 | -101.8 | -88.8 | |
| 0.00 | 0.85 | 0.00 | 0.80 | -18.89 | 82.11 | 55.88 | 247.43 | 0.8504 | -253.0 | -180.4 | |
| 0.00 | 1.71 | 0.00 | 1.63 | -20.28 | 82.68 | 56.45 | 245.98 | 0.8580 | 553.0 | 335.0 | |
| 0.51 | 1.19 | 0.48 | 1.12 | -20.87 | 81.87 | 55.65 | 245.10 | 0.8526 | -60.7 | -101.1 | |
| 0.00 | 0.60 | 0.00 | 0.53 | -20.36 | 79.84 | 53.62 | 245.14 | 0.8341 | -463.0 | -340.7 | |
| 0.00 | 1.71 | 0.00 | 1.53 | -20.74 | 79.82 | 53.60 | 244.69 | 0.8348 | -545.0 | -422.6 | |
| 0.00 | 1.36 | 0.00 | 1.20 | -20.32 | 79.35 | 53.12 | 245.03 | 0.8296 | -559.0 | -501.0 | |
| 0.00 | 0.85 | 0.00 | 0.76 | -21.50 | 79.58 | 53.35 | 243.74 | 0.8346 | 366.0 | 277.3 | |
| 0.00 | 1.19 | 0.00 | 1.05 | -21.02 | 79.17 | 52.94 | 244.17 | 0.8298 | 457.0 | 455.6 | |
| 0.00 | 1.62 | 0.00 | 1.44 | -21.34 | 79.23 | 53.00 | 243.82 | 0.8312 | 296.0 | 287.1 | |
| 0.00 | 1.28 | 0.00 | 1.13 | -21.75 | 78.91 | 52.69 | 243.24 | 0.8295 | -331.0 | -269.2 | |
| 0.00 | 0.68 | 0.00 | 0.58 | -20.09 | 77.58 | 51.36 | 244.77 | 0.8131 | -479.0 | -396.5 | |
| 0.00 | 1.11 | 0.00 | 0.93 | -20.41 | 77.27 | 51.05 | 244.30 | 0.8111 | -511.0 | -441.5 | |
| 0.00 | 1.11 | 0.00 | 0.95 | -21.30 | 77.65 | 51.42 | 243.37 | 0.8170 | -379.0 | -345.6 | |
| 0.00 | 1.19 | 0.00 | 1.02 | -21.39 | 77.44 | 51.21 | 243.19 | 0.8154 | -399.0 | -322.2 | |
| 0.00 | 2.56 | 0.00 | 2.10 | -20.94 | 75.87 | 49.65 | 243.21 | 0.7997 | -663.0 | -494.0 | |
| 0.00 | 2.64 | 0.00 | 2.22 | -22.53 | 76.43 | 50.21 | 241.50 | 0.8098 | -282.0 | -246.0 | |
| 0.00 | 0.26 | 0.00 | 0.20 | -19.89 | 73.66 | 47.44 | 243.70 | 0.7749 | -365.0 | -471.3 | |
| 0.00 | 1.11 | 0.00 | 0.92 | -23.91 | 75.24 | 49.01 | 239.44 | 0.8036 | -582.0 | -450.7 | |
| 0.00 | 0.43 | 0.00 | 0.34 | -23.55 | 74.03 | 47.81 | 239.40 | 0.7914 | -534.0 | -494.8 | |
| 0.00 | 0.43 | 0.00 | 0.35 | -25.08 | 74.41 | 48.19 | 237.75 | 0.8005 | -381.0 | -304.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
