SDO HMI 2014-12-06 18:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 59.01 | 331.19 | 31.96 | 179.48 | -3.69 | 0.95 | -23.62 | 99.58 | 0.4072 | 1104.3 | 370.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-12-06 18:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.81 | 0.00 | 1.49 | -5.28 | 4.80 | -19.76 | 105.79 | 0.3515 | 650.0 | 661.4 | |
| 0.00 | 1.02 | 0.00 | 0.55 | -7.19 | 3.71 | -20.86 | 109.94 | 0.3774 | 687.0 | 615.4 | |
| 27.63 | 318.66 | 14.93 | 172.56 | -3.74 | 1.32 | -23.25 | 99.84 | 0.4015 | 1456.4 | 381.2 | |
| 1.62 | -3.00 | 0.88 | -3.00 | -4.04 | 1.08 | -23.48 | 100.48 | 0.4060 | 767.4 | 999999 | |
| 29.76 | -3.00 | 16.15 | -3.00 | -3.48 | 0.71 | -23.86 | 98.97 | 0.4105 | 1255.7 | 999999 | |
| 0.00 | 2.56 | 0.00 | 1.40 | -3.21 | 359.91 | -24.66 | 98.07 | 0.4226 | -185.0 | -147.7 | |
| 0.00 | 1.02 | 0.00 | 0.56 | -4.78 | 359.23 | -25.33 | 101.45 | 0.4369 | 270.0 | 293.8 | |
| 0.00 | 1.36 | 0.00 | 0.77 | -11.65 | 358.61 | -25.96 | 115.55 | 0.4771 | 606.0 | 410.8 | |
| 0.00 | 0.94 | 0.00 | 0.52 | -4.78 | 359.07 | -25.50 | 101.38 | 0.4395 | 584.0 | 462.5 | |
| 0.00 | 1.11 | 0.00 | 0.62 | -4.37 | 357.50 | -27.07 | 99.89 | 0.4625 | -768.0 | -609.7 | |
| 0.00 | 1.71 | 0.00 | 1.01 | -5.08 | 351.88 | -32.69 | 99.64 | 0.5478 | -416.0 | -408.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
