SDO HMI 2014-12-10 09:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 66.25 | 328.98 | 36.00 | 179.13 | -3.84 | 1.10 | 24.29 | 261.38 | 0.4170 | 912.6 | 360.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-12-10 09:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.73 | 0.00 | 1.53 | -5.34 | 4.72 | 27.91 | 259.25 | 0.4764 | 230.0 | 275.8 | |
| 37.00 | 297.35 | 20.20 | 162.08 | -4.01 | 1.46 | 24.65 | 261.09 | 0.4230 | 1263.9 | 385.2 | |
| 0.00 | 3.75 | 0.00 | 2.04 | -2.53 | 1.00 | 24.19 | 264.49 | 0.4131 | 797.0 | 646.8 | |
| 0.94 | 4.26 | 0.51 | 2.31 | -1.53 | 0.92 | 24.11 | 266.92 | 0.4108 | -986.7 | -776.1 | |
| 20.72 | -2.00 | 11.25 | -2.00 | -3.83 | 0.80 | 24.00 | 261.29 | 0.4123 | 1325.3 | 999999 | |
| 0.00 | 1.36 | 0.00 | 0.74 | -2.33 | 0.77 | 23.96 | 264.95 | 0.4092 | 659.0 | 529.1 | |
| 0.00 | 2.22 | 0.00 | 1.20 | -1.59 | 0.66 | 23.86 | 266.75 | 0.4067 | -913.0 | -718.0 | |
| 0.00 | 1.45 | 0.00 | 0.78 | -5.20 | 359.59 | 22.78 | 257.45 | 0.3968 | 934.0 | 758.4 | |
| 0.00 | 1.02 | 0.00 | 0.55 | -2.71 | 359.48 | 22.68 | 263.70 | 0.3892 | 806.0 | 687.5 | |
| 0.00 | 2.90 | 0.00 | 1.55 | -1.83 | 359.09 | 22.28 | 265.91 | 0.3816 | 892.0 | 791.3 | |
| 0.00 | 1.11 | 0.00 | 0.59 | -2.74 | 358.91 | 22.11 | 263.47 | 0.3800 | 1069.0 | 970.5 | |
| 7.59 | 10.83 | 4.04 | 5.76 | -3.13 | 358.06 | 21.25 | 262.18 | 0.3670 | -1054.1 | -756.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
