SDO HMI 2014-12-11 18:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 41.73 | 255.32 | 28.06 | 171.51 | -4.06 | 1.10 | 42.42 | 264.48 | 0.6783 | 1005.2 | 327.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-12-11 18:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 28.96 | 244.59 | 19.53 | 164.48 | -4.12 | 1.32 | 42.64 | 264.41 | 0.6812 | 1084.9 | 321.0 | |
| 11.92 | -1.00 | 7.97 | -1.00 | -3.98 | 0.79 | 42.11 | 264.57 | 0.6743 | 1296.5 | 999999 | |
| 0.00 | 0.68 | 0.00 | 0.45 | -5.05 | 0.46 | 41.78 | 262.95 | 0.6711 | 357.0 | 396.4 | |
| 0.00 | 0.94 | 0.00 | 0.62 | -4.78 | 0.36 | 41.68 | 263.33 | 0.6695 | 407.0 | 458.1 | |
| 0.00 | 1.62 | 0.00 | 1.08 | -6.94 | 0.52 | 41.84 | 260.14 | 0.6744 | 710.0 | 530.4 | |
| 0.85 | 2.55 | 0.56 | 1.69 | -2.56 | 0.16 | 41.48 | 266.64 | 0.6652 | 717.0 | 556.7 | |
| 0.00 | 1.02 | 0.00 | 0.67 | -2.71 | 359.11 | 40.42 | 266.35 | 0.6514 | 807.0 | 607.8 | |
| 0.00 | 1.36 | 0.00 | 0.88 | -3.63 | 358.88 | 40.19 | 264.91 | 0.6490 | 712.0 | 591.5 | |
| 0.00 | 1.79 | 0.00 | 1.15 | -1.89 | 358.58 | 39.89 | 267.59 | 0.6439 | 665.0 | 497.1 | |
| 0.00 | 0.77 | 0.00 | 0.49 | -1.86 | 357.73 | 39.05 | 267.60 | 0.6325 | -336.0 | -336.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
