SDO HMI 2014-12-13 04:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 26.16 | 154.71 | 26.86 | 158.61 | -4.07 | 1.10 | 61.10 | 265.71 | 0.8776 | 635.8 | 221.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-12-13 04:00:24 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.60 | 0.00 | 0.65 | -3.33 | 3.05 | 63.06 | 266.59 | 0.8934 | -288.0 | -264.6 | |
| 0.00 | 1.02 | 0.00 | 1.07 | -2.28 | 1.67 | 61.67 | 267.76 | 0.8822 | 135.0 | 144.9 | |
| 25.73 | 146.44 | 26.44 | 150.50 | -4.15 | 1.17 | 61.17 | 265.62 | 0.8783 | 756.0 | 221.3 | |
| 0.43 | 2.39 | 0.42 | 2.35 | -2.68 | 359.81 | 59.81 | 267.27 | 0.8664 | 279.0 | 239.0 | |
| 0.00 | 2.30 | 0.00 | 2.19 | -2.69 | 358.65 | 58.65 | 267.24 | 0.8561 | 547.0 | 446.4 | |
| 0.00 | 1.36 | 0.00 | 1.29 | -2.93 | 358.55 | 58.55 | 266.96 | 0.8553 | 471.0 | 420.5 | |
| 0.00 | 0.60 | 0.00 | 0.56 | -1.72 | 358.41 | 58.42 | 268.38 | 0.8539 | -359.0 | -321.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
