SOHO MDI 1999-12-05 18:59:33 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 178 | 1158 | 122 | 820 | 10.21 | 309.07 | -44.41 | 75.65 | 0.7077 | 617.2 | 101.6 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 1999-12-05 18:59:33 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0 | 3 | 0 | 2 | 14.00 | 300.71 | -52.77 | 72.80 | 0.8110 | -206.0 | -167.2 | |
| 19 | 654 | 12 | 417 | 10.14 | 315.67 | -37.81 | 74.04 | 0.6299 | 1603.4 | 595.3 | |
| 46 | -2 | 29 | -2 | 9.63 | 315.65 | -37.83 | 74.85 | 0.6287 | 1965.5 | 999999 | |
| 3 | 11 | 2 | 7 | 10.29 | 312.27 | -41.21 | 74.87 | 0.6739 | 649.0 | 422.0 | |
| 21 | -2 | 13 | -2 | 9.35 | 314.81 | -38.67 | 75.54 | 0.6390 | 1119.4 | 999999 | |
| 0 | 3 | 0 | 2 | 9.72 | 313.33 | -40.15 | 75.41 | 0.6591 | 373.0 | 256.0 | |
| 27 | -2 | 17 | -2 | 8.99 | 315.37 | -38.11 | 75.94 | 0.6307 | 1708.9 | 999999 | |
| 0 | 7 | 0 | 5 | 9.94 | 311.98 | -41.50 | 75.47 | 0.6767 | 628.0 | 517.1 | |
| 5 | 14 | 3 | 9 | 9.71 | 312.50 | -40.97 | 75.65 | 0.6695 | 985.0 | 687.6 | |
| 0 | 5 | 0 | 4 | 12.04 | 300.28 | -53.20 | 75.26 | 0.8120 | 164.0 | 114.4 | |
| 3 | 8 | 2 | 5 | 10.15 | 307.97 | -45.51 | 76.16 | 0.7256 | 417.3 | 286.5 | |
| 5 | 392 | 4 | 321 | 11.61 | 301.58 | -51.90 | 75.56 | 0.7983 | -692.4 | -516.4 | |
| 0 | 10 | 0 | 7 | 8.99 | 312.24 | -41.24 | 76.79 | 0.6712 | 905.0 | 718.5 | |
| 16 | -12 | 13 | -12 | 11.18 | 302.10 | -51.38 | 76.00 | 0.7922 | -1265.3 | 999999 | |
| 0 | 3 | 0 | 2 | 8.91 | 311.21 | -42.27 | 77.16 | 0.6839 | 391.0 | 368.7 | |
| 25 | -12 | 20 | -12 | 11.26 | 301.18 | -52.30 | 76.07 | 0.8018 | -752.5 | 999999 | |
| 0 | 4 | 0 | 3 | 10.40 | 303.79 | -49.69 | 76.68 | 0.7731 | -638.0 | -584.7 | |
| 0 | 4 | 0 | 3 | 8.86 | 309.43 | -44.05 | 77.62 | 0.7058 | 578.0 | 528.0 | |
| 8 | -12 | 7 | -12 | 10.69 | 301.65 | -51.83 | 76.70 | 0.7962 | -1078.1 | 999999 | |
| 0 | 3 | 0 | 2 | 9.53 | 304.29 | -49.19 | 77.71 | 0.7663 | -612.0 | -597.5 | |
| 0 | 6 | 0 | 5 | 10.17 | 301.31 | -52.17 | 77.40 | 0.7989 | -662.0 | -645.8 | |
| 0 | 8 | 0 | 7 | 9.64 | 301.37 | -52.10 | 78.05 | 0.7975 | -631.0 | -494.6 | |
| 0 | 18 | 0 | 15 | 9.89 | 299.82 | -53.66 | 77.97 | 0.8136 | 261.0 | 98.8 | |
| 0 | 5 | 0 | 4 | 9.53 | 300.58 | -52.90 | 78.30 | 0.8056 | -346.0 | -338.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
