group	Proj. U	Proj. WS	Corr. U	Corr. WS	B	L	LCM	Pos. angle	r	MU	MP
8788	223	1506	122	822	9.81	311.64	21.49	298.53	0.4073	513.9	183.6

previous   or   next   observation for the same group / back to the solar disc SOHO MDI 1999-12-10 14:23:33 UT

spot	Proj. U	Proj. WS	Corr. U	Corr. WS	B	L	LCM	Pos. angle	r	MU	MP
1	0	3	0	2	11.90	317.66	27.52	295.07	0.5012	-541.0	-391.8
2	0	6	0	3	6.15	316.80	26.66	284.17	0.4620	-452.0	-262.4
3	127	813	72	458	9.48	316.95	26.80	290.93	0.4781	1737.2	697.5
4	3	-3	2	-3	9.59	315.27	25.13	292.34	0.4546	1385.1	999999
5	0	3	0	2	11.89	315.26	25.12	296.98	0.4680	-378.0	-411.2
6	0	6	0	3	9.04	314.80	24.66	291.55	0.4449	694.0	650.4
7	0	7	0	4	10.95	314.66	24.51	295.63	0.4537	185.0	172.9
8	4	56	2	30	6.92	313.86	23.72	287.51	0.4205	961.2	-248.0
9	5	16	3	9	9.55	314.03	23.89	293.23	0.4364	1240.6	990.2
10	3	48	2	26	9.08	313.83	23.68	292.39	0.4308	1201.9	750.4
11	5	-10	3	-10	8.69	313.63	23.49	291.69	0.4258	761.2	999999
12	3	-8	1	-8	7.42	313.47	23.32	288.93	0.4169	-1179.7	999999
13	0	4	0	2	8.34	313.15	23.00	291.29	0.4167	849.0	705.8
14	0	6	0	4	9.43	313.05	22.90	293.80	0.4215	1210.0	1000.6
15	0	2	0	1	8.61	313.00	22.85	292.03	0.4160	904.0	876.2
16	0	8	0	4	9.15	312.74	22.59	293.47	0.4153	914.0	934.5
17	0	4	0	2	9.11	311.31	21.17	294.70	0.3942	882.0	676.5
18	0	3	0	2	8.10	310.22	20.08	293.34	0.3718	646.0	695.5
19	0	5	0	3	7.79	309.26	19.12	293.53	0.3555	911.0	718.8
20	0	5	0	3	8.18	307.98	17.83	296.02	0.3389	781.0	659.4
21	0	3	0	2	10.93	305.00	14.86	307.81	0.3201	-636.0	-529.2
22	0	7	0	4	12.61	303.60	13.45	314.62	0.3204	772.0	618.4
23	0	11	0	6	12.37	303.06	12.92	315.22	0.3114	-548.0	-504.0
24	36	470	18	242	10.38	302.14	11.99	312.31	0.2776	-1874.1	-796.9
25	0	6	0	3	8.16	301.55	11.40	307.10	0.2465	-871.0	-715.0
26	8	-24	4	-24	10.61	301.43	11.28	314.65	0.2716	-1850.5	999999
27	25	-24	13	-24	11.54	301.43	11.28	317.07	0.2827	-1707.0	999999
28	0	1	0	1	5.20	301.01	10.86	297.24	0.2120	-644.0	-521.1
29	4	-24	2	-24	11.15	301.13	10.99	316.83	0.2746	-1839.6	999999
30	0	6	0	3	8.05	300.80	10.65	308.58	0.2352	-773.0	-709.5
31	0	7	0	3	14.25	300.03	9.88	326.58	0.3034	-920.0	-729.5

	Proj. U	-  Projected umbra area in millionths of solar disc, negative values indicate
	that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2.
	Proj. WS	-  Projected whole spot area in millionths of solar disc, negative values indicate
	that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7.
	Corr. U	-  Corrected umbra area in millionths of solar hemisphere, for negative values see above
	Corr. WS	-  Corrected whole spot area in millionths of solar hemisphere, for negative values see above
	B	-  Heliographic latitude B; positive: North, negative: South
	L	-  Heliographic longitude L
	LCM	-  Longitudinal distance from the Sun's central meridian
	Pos. angle	-  Position angle
	r	-  Distance from the centre of Sun's disc in terms of Sun's radius
	MU	-  Mean magnetic field within the umbra contour averaged the pixel values with sign.
	MP	-  Mean magnetic field within the penumbra contour averaged the pixel values with sign.
