SOHO MDI 1999-12-12 09:35:32 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 147 | 1000 | 109 | 729 | 9.85 | 312.20 | 45.76 | 284.54 | 0.7262 | 71.9 | 33.9 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 1999-12-12 09:35:32 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 95 | 562 | 76 | 448 | 9.55 | 317.31 | 50.87 | 282.69 | 0.7864 | 711.3 | 367.9 | |
| 0 | 11 | 0 | 9 | 9.61 | 315.08 | 48.65 | 283.19 | 0.7625 | 890.0 | 802.4 | |
| 0 | 12 | 0 | 9 | 10.27 | 315.10 | 48.66 | 284.05 | 0.7639 | 435.0 | 319.6 | |
| 0 | 3 | 0 | 2 | 5.73 | 314.32 | 47.88 | 278.22 | 0.7481 | 415.0 | 333.1 | |
| 0 | 4 | 0 | 3 | 9.96 | 314.92 | 48.48 | 283.68 | 0.7613 | 596.0 | 498.9 | |
| 0 | 13 | 0 | 10 | 9.06 | 314.69 | 48.25 | 282.56 | 0.7572 | 914.0 | 708.4 | |
| 0 | 2 | 0 | 2 | 8.12 | 303.41 | 36.97 | 284.08 | 0.6162 | -420.0 | -403.1 | |
| 16 | 360 | 10 | 226 | 10.14 | 303.36 | 36.93 | 287.29 | 0.6217 | -1272.9 | -621.2 | |
| 8 | -8 | 5 | -8 | 10.30 | 303.00 | 36.56 | 287.67 | 0.6174 | -1381.0 | 999999 | |
| 6 | -8 | 4 | -8 | 10.37 | 302.43 | 35.99 | 288.02 | 0.6102 | -1399.8 | 999999 | |
| 22 | -8 | 14 | -8 | 11.03 | 302.23 | 35.79 | 289.16 | 0.6100 | -1481.6 | 999999 | |
| 0 | 17 | 0 | 11 | 9.63 | 302.04 | 35.61 | 286.99 | 0.6025 | -1049.0 | -908.7 | |
| 0 | 3 | 0 | 2 | 9.01 | 301.83 | 35.39 | 286.06 | 0.5975 | -677.0 | -525.3 | |
| 0 | 4 | 0 | 2 | 9.66 | 300.91 | 34.47 | 287.51 | 0.5873 | 184.0 | 198.3 | |
| 0 | 9 | 0 | 5 | 8.60 | 299.53 | 33.09 | 286.31 | 0.5647 | -815.0 | -819.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
