SOHO MDI 2000-01-24 16:14:32 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 63 | 437 | 42 | 277 | -29.20 | 24.15 | -32.21 | 131.96 | 0.6260 | -1074.6 | -323.1 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2000-01-24 16:14:32 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4 | 349 | 3 | 217 | -28.90 | 26.19 | -30.16 | 133.01 | 0.6038 | -1327.8 | -494.7 | |
| 4 | -1 | 3 | -1 | -29.18 | 25.75 | -30.61 | 133.03 | 0.6105 | -919.0 | 999999 | |
| 0 | 3 | 0 | 2 | -27.44 | 26.20 | -30.16 | 130.95 | 0.5926 | -202.0 | -269.2 | |
| 43 | -1 | 27 | -1 | -28.67 | 25.66 | -30.70 | 132.26 | 0.6075 | -1599.4 | 999999 | |
| 0 | 3 | 0 | 2 | -28.10 | 22.40 | -33.96 | 129.09 | 0.6372 | 652.0 | 426.2 | |
| 2 | 43 | 2 | 29 | -30.95 | 19.40 | -36.96 | 130.98 | 0.6854 | 447.9 | 103.2 | |
| 3 | -6 | 2 | -6 | -31.28 | 19.13 | -37.22 | 131.24 | 0.6899 | -861.5 | 999999 | |
| 0 | 3 | 0 | 2 | -32.09 | 18.01 | -38.35 | 131.59 | 0.7053 | 600.0 | 483.2 | |
| 0 | 4 | 0 | 3 | -29.48 | 18.16 | -38.20 | 128.34 | 0.6888 | 750.0 | 625.1 | |
| 0 | 5 | 0 | 3 | -31.81 | 16.87 | -39.49 | 130.61 | 0.7143 | 258.0 | 324.3 | |
| 0 | 4 | 0 | 3 | -30.90 | 16.80 | -39.56 | 129.43 | 0.7098 | 484.0 | 591.5 | |
| 7 | 20 | 5 | 14 | -31.35 | 16.34 | -40.02 | 129.75 | 0.7166 | 704.3 | 584.4 | |
| 0 | 3 | 0 | 2 | -29.81 | 16.41 | -39.95 | 127.82 | 0.7077 | 427.0 | 390.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
