SOHO MDI 2000-01-26 20:47:32 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 64 | 477 | 35 | 258 | -28.93 | 23.41 | -4.10 | 171.19 | 0.4044 | -1618.7 | -460.6 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2000-01-26 20:47:32 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0 | 13 | 0 | 7 | -26.94 | 24.34 | -3.18 | 172.29 | 0.3698 | -717.0 | -607.9 | |
| 0 | 4 | 0 | 2 | -26.12 | 24.32 | -3.20 | 171.89 | 0.3566 | 421.0 | 318.8 | |
| 60 | 407 | 33 | 220 | -28.81 | 24.06 | -3.45 | 172.39 | 0.4002 | -1914.3 | -604.1 | |
| 0 | 10 | 0 | 5 | -30.05 | 21.58 | -5.93 | 167.83 | 0.4264 | 625.0 | 539.6 | |
| 0 | 4 | 0 | 2 | -29.24 | 21.14 | -6.37 | 166.46 | 0.4156 | 690.0 | 505.1 | |
| 4 | 9 | 2 | 5 | -31.49 | 18.54 | -8.97 | 163.13 | 0.4601 | 884.3 | 600.2 | |
| 0 | 5 | 0 | 3 | -31.91 | 17.77 | -9.74 | 162.11 | 0.4697 | 493.0 | 547.4 | |
| 0 | 5 | 0 | 3 | -31.05 | 17.40 | -10.11 | 160.80 | 0.4591 | 617.0 | 546.6 | |
| 0 | 4 | 0 | 2 | -29.73 | 16.82 | -10.69 | 158.60 | 0.4433 | 916.0 | 792.8 | |
| 0 | 5 | 0 | 3 | -29.98 | 16.35 | -11.16 | 157.99 | 0.4495 | 682.0 | 611.9 | |
| 0 | 3 | 0 | 2 | -31.07 | 16.13 | -11.39 | 158.64 | 0.4663 | 575.0 | 588.1 | |
| 0 | 4 | 0 | 2 | -28.13 | 16.37 | -11.14 | 156.16 | 0.4234 | 812.0 | 744.5 | |
| 0 | 4 | 0 | 2 | -30.72 | 15.53 | -11.98 | 157.32 | 0.4648 | 831.0 | 801.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
