SOHO MDI 2000-07-04 04:47:31 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 81 | 498 | 46 | 286 | -20.07 | 64.19 | -19.75 | 141.13 | 0.5075 | -1726.2 | -558.8 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2000-07-04 04:47:31 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 81 | 486 | 46 | 279 | -20.28 | 64.30 | -19.63 | 141.54 | 0.5088 | -1754.6 | -578.9 | |
| -1 | -1 | -1 | -1 | -19.85 | 64.27 | -19.67 | 140.93 | 0.5042 | 999999 | 999999 | |
| 0 | 4 | 0 | 3 | -20.62 | 62.63 | -21.30 | 139.75 | 0.5284 | -87.0 | -225.6 | |
| 0 | 4 | 0 | 2 | -21.58 | 58.91 | -25.02 | 136.57 | 0.5744 | 820.0 | 600.4 | |
| 0 | 4 | 0 | 2 | -19.00 | 58.43 | -25.51 | 132.58 | 0.5550 | 632.0 | 593.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
