SOHO MDI 2000-07-06 04:47:31 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 136 | 946 | 77 | 513 | -18.44 | 49.20 | -8.26 | 160.34 | 0.4005 | -766.3 | -193.5 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2000-07-06 04:47:31 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0 | 5 | 0 | 3 | -16.26 | 52.70 | -4.75 | 166.75 | 0.3488 | -403.0 | -308.8 | |
| 46 | 344 | 25 | 184 | -17.78 | 52.24 | -5.21 | 166.60 | 0.3747 | -2064.2 | -715.8 | |
| -2 | -2 | -2 | -2 | -17.87 | 51.74 | -5.72 | 165.42 | 0.3781 | 999999 | 999999 | |
| 4 | 11 | 2 | 6 | -15.85 | 50.93 | -6.52 | 161.74 | 0.3502 | -1088.3 | -760.7 | |
| 0 | 3 | 0 | 2 | -16.27 | 50.71 | -6.74 | 161.56 | 0.3579 | -670.0 | -633.2 | |
| 3 | 80 | 2 | 42 | -16.78 | 50.61 | -6.85 | 161.76 | 0.3662 | -1378.4 | -912.4 | |
| 13 | -6 | 7 | -6 | -17.24 | 50.38 | -7.07 | 161.62 | 0.3746 | -1566.4 | 999999 | |
| 5 | 15 | 3 | 8 | -18.56 | 50.28 | -7.17 | 162.51 | 0.3953 | -1188.0 | -898.6 | |
| 0 | 5 | 0 | 3 | -20.76 | 50.18 | -7.27 | 163.93 | 0.4291 | -762.0 | -488.5 | |
| 0 | 25 | 0 | 14 | -19.08 | 50.14 | -7.32 | 162.58 | 0.4038 | -1133.0 | -679.8 | |
| 3 | -6 | 2 | -6 | -17.42 | 50.16 | -7.29 | 161.26 | 0.3783 | -1368.7 | 999999 | |
| 0 | 4 | 0 | 2 | -20.33 | 49.86 | -7.59 | 162.95 | 0.4241 | -707.0 | -489.8 | |
| 0 | 3 | 0 | 2 | -17.12 | 49.80 | -7.65 | 160.12 | 0.3758 | -323.0 | -352.0 | |
| 0 | 4 | 0 | 2 | -17.80 | 49.69 | -7.77 | 160.48 | 0.3867 | -816.0 | -850.0 | |
| 0 | 8 | 0 | 5 | -17.46 | 49.53 | -7.92 | 159.81 | 0.3824 | -1052.0 | -771.0 | |
| 0 | 11 | 0 | 6 | -16.62 | 49.40 | -8.05 | 158.67 | 0.3704 | 522.0 | 207.5 | |
| 5 | 13 | 3 | 7 | -20.17 | 48.98 | -8.47 | 160.97 | 0.4259 | -1115.3 | -630.6 | |
| 8 | 68 | 5 | 37 | -18.79 | 48.97 | -8.49 | 159.76 | 0.4055 | -1267.9 | -594.6 | |
| 0 | 26 | 0 | 14 | -18.19 | 49.00 | -8.46 | 159.27 | 0.3964 | -1179.0 | -774.9 | |
| 4 | -18 | 2 | -18 | -18.58 | 48.72 | -8.73 | 159.03 | 0.4037 | -1280.0 | 999999 | |
| 3 | 34 | 2 | 18 | -16.46 | 48.58 | -8.88 | 156.53 | 0.3732 | 1023.8 | 884.8 | |
| 4 | -18 | 2 | -18 | -18.88 | 48.28 | -9.17 | 158.37 | 0.4108 | -926.2 | 999999 | |
| 3 | -21 | 2 | -21 | -16.25 | 48.29 | -9.16 | 155.63 | 0.3720 | 1430.2 | 999999 | |
| 0 | 3 | 0 | 1 | -16.84 | 48.18 | -9.27 | 156.04 | 0.3814 | 618.0 | 553.1 | |
| 4 | -21 | 2 | -21 | -16.55 | 48.07 | -9.38 | 155.45 | 0.3778 | 1152.8 | 999999 | |
| 0 | 4 | 0 | 2 | -16.93 | 47.88 | -9.57 | 155.46 | 0.3846 | 738.0 | 618.5 | |
| 6 | 29 | 3 | 16 | -20.18 | 47.57 | -9.89 | 158.11 | 0.4340 | -926.8 | -204.5 | |
| 0 | 24 | 0 | 13 | -19.46 | 46.80 | -10.65 | 155.88 | 0.4283 | 780.0 | 935.9 | |
| 0 | 4 | 0 | 2 | -17.49 | 46.88 | -10.57 | 153.92 | 0.3996 | 705.0 | 583.5 | |
| 0 | 14 | 0 | 8 | -20.58 | 46.42 | -11.03 | 156.26 | 0.4467 | 587.0 | 478.9 | |
| 0 | 6 | 0 | 3 | -18.91 | 46.24 | -11.21 | 154.18 | 0.4242 | 1093.0 | 955.1 | |
| 0 | 3 | 0 | 2 | -18.18 | 46.16 | -11.29 | 153.22 | 0.4145 | 878.0 | 873.7 | |
| 4 | 12 | 2 | 7 | -19.77 | 45.97 | -11.49 | 154.57 | 0.4382 | 1254.0 | 900.5 | |
| 0 | 3 | 0 | 2 | -17.84 | 46.10 | -11.35 | 152.69 | 0.4102 | 878.0 | 755.6 | |
| 0 | 3 | 0 | 2 | -18.18 | 45.95 | -11.50 | 152.79 | 0.4161 | 1167.0 | 1042.0 | |
| 3 | 8 | 2 | 4 | -20.55 | 45.52 | -11.93 | 154.53 | 0.4522 | 1041.6 | 770.2 | |
| 6 | 110 | 4 | 61 | -19.13 | 45.41 | -12.04 | 152.81 | 0.4332 | 1465.5 | 1069.8 | |
| 0 | 8 | 0 | 4 | -20.73 | 45.07 | -12.38 | 153.90 | 0.4577 | 741.0 | 492.0 | |
| 2 | -37 | 1 | -37 | -18.92 | 45.17 | -12.28 | 152.11 | 0.4320 | 1265.9 | 999999 | |
| 3 | -37 | 2 | -37 | -20.04 | 45.00 | -12.46 | 153.03 | 0.4487 | 1185.9 | 999999 | |
| 2 | -37 | 1 | -37 | -19.78 | 44.89 | -12.56 | 152.55 | 0.4459 | 1284.5 | 999999 | |
| 0 | 6 | 0 | 3 | -20.61 | 44.39 | -13.07 | 152.54 | 0.4608 | 809.0 | 738.0 | |
| 0 | 11 | 0 | 6 | -20.53 | 44.18 | -13.28 | 152.08 | 0.4612 | 873.0 | 710.7 | |
| 0 | 6 | 0 | 3 | -19.75 | 44.16 | -13.30 | 151.18 | 0.4509 | 627.0 | 691.8 | |
| 0 | 5 | 0 | 3 | -21.10 | 44.04 | -13.41 | 152.45 | 0.4698 | 868.0 | 615.9 | |
| 0 | 3 | 0 | 2 | -23.08 | 43.75 | -13.70 | 153.97 | 0.4983 | 537.0 | 520.5 | |
| 0 | 4 | 0 | 2 | -22.07 | 43.51 | -13.95 | 152.55 | 0.4866 | 798.0 | 660.7 | |
| 5 | 12 | 3 | 7 | -19.59 | 43.65 | -13.80 | 150.09 | 0.4525 | 1061.6 | 846.1 | |
| 0 | 4 | 0 | 2 | -21.50 | 43.34 | -14.11 | 151.69 | 0.4802 | 967.0 | 805.5 | |
| 0 | 5 | 0 | 3 | -20.53 | 41.47 | -15.99 | 147.52 | 0.4823 | 921.0 | 747.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
