SOHO MDI 2000-07-06 09:35:31 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 129 | 984 | 70 | 529 | -18.30 | 49.17 | -5.63 | 166.29 | 0.3866 | -517.1 | -218.8 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2000-07-06 09:35:31 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 48 | 344 | 25 | 183 | -17.84 | 52.13 | -2.67 | 173.06 | 0.3686 | -2068.9 | -717.5 | |
| -1 | -1 | -1 | -1 | -17.88 | 51.63 | -3.17 | 171.79 | 0.3704 | 999999 | 999999 | |
| 0 | 8 | 0 | 4 | -15.81 | 50.93 | -3.88 | 168.88 | 0.3389 | -1186.0 | -923.8 | |
| 4 | 124 | 2 | 66 | -16.70 | 50.62 | -4.19 | 168.57 | 0.3542 | -1431.3 | -996.1 | |
| 8 | -4 | 4 | -4 | -17.21 | 50.52 | -4.28 | 168.61 | 0.3626 | -1756.4 | 999999 | |
| 0 | 3 | 0 | 1 | -19.43 | 50.13 | -4.67 | 168.85 | 0.3991 | -572.0 | -545.4 | |
| 4 | 50 | 2 | 27 | -18.57 | 50.11 | -4.69 | 168.35 | 0.3856 | -1219.3 | -749.8 | |
| 0 | 4 | 0 | 2 | -20.51 | 49.89 | -4.92 | 168.85 | 0.4168 | -465.0 | -363.9 | |
| 0 | 3 | 0 | 2 | -18.02 | 49.46 | -5.34 | 166.43 | 0.3792 | -840.0 | -733.7 | |
| 0 | 3 | 0 | 2 | -17.76 | 49.22 | -5.59 | 165.67 | 0.3762 | -767.0 | -691.2 | |
| 3 | 11 | 2 | 6 | -20.21 | 49.13 | -5.67 | 167.02 | 0.4146 | -1269.1 | -786.5 | |
| 7 | 79 | 4 | 42 | -18.83 | 49.14 | -5.66 | 166.20 | 0.3932 | -1180.1 | -753.5 | |
| 3 | -12 | 2 | -12 | -18.58 | 48.85 | -5.95 | 165.36 | 0.3904 | -1304.6 | 999999 | |
| 3 | 77 | 2 | 41 | -16.37 | 48.84 | -5.96 | 163.67 | 0.3559 | 1125.1 | 745.9 | |
| 5 | -14 | 2 | -14 | -16.46 | 48.43 | -6.38 | 162.67 | 0.3593 | 1390.0 | 999999 | |
| 10 | -14 | 5 | -14 | -16.50 | 48.05 | -6.75 | 161.76 | 0.3618 | 1376.5 | 999999 | |
| 4 | 13 | 2 | 7 | -20.13 | 47.74 | -7.07 | 163.93 | 0.4190 | -946.5 | -734.0 | |
| 0 | 8 | 0 | 4 | -19.01 | 47.70 | -7.10 | 163.02 | 0.4021 | -566.0 | -317.7 | |
| 0 | 4 | 0 | 2 | -16.93 | 47.79 | -7.02 | 161.49 | 0.3697 | 822.0 | 712.5 | |
| 0 | 4 | 0 | 2 | -19.41 | 47.09 | -7.71 | 161.98 | 0.4110 | 143.0 | 144.8 | |
| 0 | 3 | 0 | 2 | -19.84 | 47.03 | -7.78 | 162.19 | 0.4178 | 455.0 | 389.6 | |
| 0 | 5 | 0 | 3 | -17.70 | 47.00 | -7.80 | 160.32 | 0.3856 | 752.0 | 675.8 | |
| 3 | 20 | 2 | 11 | -19.71 | 46.31 | -8.49 | 160.57 | 0.4196 | 1173.6 | 791.8 | |
| 0 | 17 | 0 | 9 | -20.76 | 46.08 | -8.72 | 160.95 | 0.4363 | 922.0 | 534.4 | |
| 0 | 4 | 0 | 2 | -17.88 | 45.98 | -8.82 | 158.17 | 0.3941 | 1157.0 | 935.7 | |
| 3 | 10 | 2 | 5 | -19.76 | 45.84 | -8.96 | 159.62 | 0.4229 | 1186.4 | 871.2 | |
| 0 | 10 | 0 | 6 | -20.63 | 45.49 | -9.31 | 159.66 | 0.4376 | 1000.0 | 835.8 | |
| 6 | 87 | 3 | 48 | -19.16 | 45.49 | -9.31 | 158.35 | 0.4161 | 1559.2 | 1009.1 | |
| 3 | -28 | 2 | -28 | -18.95 | 45.21 | -9.60 | 157.55 | 0.4147 | 1421.0 | 999999 | |
| 0 | 3 | 0 | 2 | -20.72 | 45.05 | -9.75 | 158.88 | 0.4413 | 857.0 | 718.1 | |
| 6 | 42 | 4 | 23 | -19.86 | 44.85 | -9.95 | 157.69 | 0.4300 | 1324.0 | 1001.9 | |
| 3 | -31 | 2 | -31 | -19.34 | 44.84 | -9.96 | 157.18 | 0.4226 | 1400.5 | 999999 | |
| 0 | 4 | 0 | 2 | -20.42 | 44.56 | -10.25 | 157.64 | 0.4399 | 1055.0 | 910.1 | |
| 0 | 7 | 0 | 4 | -20.34 | 44.31 | -10.50 | 157.07 | 0.4402 | 1073.0 | 694.4 | |
| 0 | 4 | 0 | 2 | -20.17 | 43.80 | -11.00 | 155.93 | 0.4410 | 683.0 | 538.5 | |
| 0 | 7 | 0 | 4 | -21.48 | 43.49 | -11.32 | 156.59 | 0.4615 | 832.0 | 724.1 | |
| 0 | 5 | 0 | 3 | -22.05 | 43.44 | -11.36 | 157.03 | 0.4698 | 658.0 | 579.1 | |
| 6 | 14 | 3 | 8 | -19.44 | 43.60 | -11.21 | 154.79 | 0.4320 | 1312.0 | 839.0 | |
| 0 | 7 | 0 | 4 | -20.51 | 41.49 | -13.32 | 152.00 | 0.4615 | 777.0 | 590.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
