SOHO MDI 2000-07-07 01:35:31 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 134 | 990 | 72 | 531 | -18.10 | 49.43 | 3.46 | 188.99 | 0.3783 | -993.5 | -238.0 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2000-07-07 01:35:31 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 56 | 325 | 30 | 174 | -17.87 | 52.00 | 6.03 | 195.29 | 0.3807 | -2062.4 | -618.4 | |
| 0 | 5 | 0 | 3 | -14.91 | 51.87 | 5.89 | 197.37 | 0.3339 | -826.0 | -657.9 | |
| -1 | -1 | -1 | -1 | -17.99 | 51.47 | 5.49 | 193.89 | 0.3805 | 999999 | 999999 | |
| 0 | 4 | 0 | 2 | -15.70 | 51.11 | 5.13 | 194.61 | 0.3429 | 445.0 | 234.8 | |
| 0 | 4 | 0 | 2 | -20.35 | 51.25 | 5.27 | 191.98 | 0.4166 | -724.0 | -607.1 | |
| 7 | 280 | 4 | 148 | -16.25 | 50.83 | 4.86 | 193.47 | 0.3505 | -1569.6 | -688.8 | |
| 7 | -6 | 4 | -6 | -16.80 | 50.81 | 4.83 | 193.02 | 0.3591 | -1891.9 | 999999 | |
| 8 | -6 | 4 | -6 | -17.14 | 50.65 | 4.67 | 192.40 | 0.3639 | -1782.7 | 999999 | |
| 0 | 6 | 0 | 3 | -18.07 | 50.59 | 4.61 | 191.70 | 0.3786 | -393.0 | -441.8 | |
| 5 | -6 | 3 | -6 | -17.52 | 50.28 | 4.31 | 191.24 | 0.3688 | -1439.5 | 999999 | |
| 5 | -6 | 3 | -6 | -17.98 | 50.04 | 4.07 | 190.39 | 0.3755 | -1254.7 | 999999 | |
| 5 | 39 | 3 | 21 | -18.58 | 49.85 | 3.87 | 189.62 | 0.3845 | -992.3 | -840.1 | |
| 0 | 4 | 0 | 2 | -19.31 | 49.78 | 3.80 | 189.14 | 0.3959 | -674.0 | -623.5 | |
| 4 | 8 | 2 | 4 | -20.21 | 49.51 | 3.53 | 188.15 | 0.4096 | -842.6 | -716.0 | |
| 5 | -12 | 2 | -12 | -18.92 | 49.44 | 3.46 | 188.48 | 0.3889 | -1099.6 | 999999 | |
| 3 | 16 | 2 | 9 | -18.23 | 49.17 | 3.20 | 188.10 | 0.3773 | -1408.0 | -1156.1 | |
| 0 | 10 | 0 | 5 | -19.05 | 48.89 | 2.92 | 187.12 | 0.3897 | -466.0 | -333.3 | |
| 0 | 6 | 0 | 3 | -18.53 | 48.59 | 2.62 | 186.55 | 0.3808 | -328.0 | -312.9 | |
| 0 | 6 | 0 | 3 | -16.92 | 48.40 | 2.43 | 186.59 | 0.3543 | 982.0 | 650.8 | |
| 0 | 3 | 0 | 2 | -19.00 | 48.18 | 2.20 | 185.40 | 0.3877 | -730.0 | -627.1 | |
| 0 | 4 | 0 | 2 | -19.99 | 48.07 | 2.09 | 184.90 | 0.4034 | -729.0 | -465.1 | |
| 0 | 4 | 0 | 2 | -16.28 | 47.82 | 1.84 | 185.18 | 0.3430 | 1131.0 | 1021.0 | |
| 0 | 2 | 0 | 1 | -18.06 | 47.59 | 1.61 | 184.13 | 0.3717 | 639.0 | 580.0 | |
| 0 | 4 | 0 | 2 | -19.34 | 47.56 | 1.58 | 183.81 | 0.3924 | -725.0 | -503.4 | |
| 0 | 3 | 0 | 2 | -19.82 | 47.52 | 1.54 | 183.64 | 0.4000 | -530.0 | -428.9 | |
| 5 | 50 | 3 | 27 | -16.79 | 47.33 | 1.35 | 183.70 | 0.3506 | 1468.2 | 759.9 | |
| 0 | 12 | 0 | 6 | -17.93 | 47.29 | 1.32 | 183.41 | 0.3693 | 1162.0 | 732.4 | |
| 8 | -26 | 4 | -26 | -16.53 | 47.16 | 1.18 | 183.29 | 0.3463 | 1533.1 | 999999 | |
| 0 | 5 | 0 | 3 | -18.74 | 46.71 | 0.74 | 181.83 | 0.3820 | 892.0 | 599.7 | |
| 0 | 4 | 0 | 2 | -21.16 | 46.22 | 0.24 | 180.53 | 0.4207 | 534.0 | 576.8 | |
| 0 | 54 | 0 | 29 | -19.09 | 45.54 | -0.44 | 178.93 | 0.3875 | 1515.0 | 1015.3 | |
| 8 | 21 | 4 | 12 | -20.64 | 45.45 | -0.52 | 178.81 | 0.4125 | 1215.5 | 827.5 | |
| 0 | 12 | 0 | 6 | -19.86 | 45.25 | -0.73 | 178.27 | 0.4001 | 1204.0 | 885.2 | |
| 0 | 4 | 0 | 2 | -20.51 | 45.03 | -0.95 | 177.83 | 0.4106 | 1000.0 | 839.1 | |
| 0 | 5 | 0 | 3 | -20.95 | 44.99 | -0.99 | 177.77 | 0.4175 | 696.0 | 655.2 | |
| 3 | 36 | 1 | 19 | -19.90 | 44.74 | -1.24 | 177.09 | 0.4011 | 1218.7 | 1094.6 | |
| 0 | 8 | 0 | 5 | -20.38 | 44.65 | -1.33 | 176.95 | 0.4088 | 1152.0 | 944.2 | |
| 0 | 3 | 0 | 2 | -21.25 | 44.64 | -1.33 | 177.05 | 0.4226 | 175.0 | 199.4 | |
| 5 | -36 | 3 | -36 | -19.65 | 44.62 | -1.36 | 176.75 | 0.3970 | 1387.0 | 999999 | |
| 0 | 15 | 0 | 8 | -20.34 | 44.23 | -1.75 | 175.97 | 0.4085 | 1277.0 | 912.5 | |
| 0 | 3 | 0 | 2 | -22.09 | 43.99 | -1.98 | 175.77 | 0.4365 | 777.0 | 656.4 | |
| 0 | 8 | 0 | 5 | -21.39 | 43.45 | -2.53 | 174.45 | 0.4262 | 971.0 | 746.0 | |
| 0 | 5 | 0 | 3 | -23.06 | 43.38 | -2.60 | 174.69 | 0.4525 | 546.0 | 514.8 | |
| 0 | 5 | 0 | 3 | -19.22 | 43.40 | -2.58 | 173.76 | 0.3918 | 1108.0 | 921.5 | |
| 0 | 3 | 0 | 2 | -17.81 | 43.17 | -2.80 | 172.73 | 0.3695 | 698.0 | 629.2 | |
| 0 | 4 | 0 | 2 | -17.68 | 42.88 | -3.09 | 171.94 | 0.3681 | 916.0 | 703.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
