SOHO MDI 2000-07-07 20:47:31 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 146 | 1055 | 79 | 580 | -18.32 | 49.24 | 13.86 | 211.28 | 0.4407 | -858.7 | -324.9 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2000-07-07 20:47:31 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0 | 4 | 0 | 2 | -20.51 | 52.29 | 16.90 | 213.77 | 0.4919 | -536.0 | -575.4 | |
| 61 | 576 | 34 | 319 | -18.00 | 51.89 | 16.51 | 216.36 | 0.4577 | -1825.9 | -761.2 | |
| 7 | -2 | 4 | -2 | -16.63 | 51.17 | 15.78 | 217.06 | 0.4341 | -1687.5 | 999999 | |
| -2 | -2 | -2 | -2 | -18.12 | 51.25 | 15.87 | 215.14 | 0.4533 | 999999 | 999999 | |
| 6 | -2 | 3 | -2 | -17.05 | 50.90 | 15.51 | 216.01 | 0.4368 | -1867.6 | 999999 | |
| 8 | -2 | 4 | -2 | -17.64 | 50.48 | 15.09 | 214.46 | 0.4403 | -1617.4 | 999999 | |
| 0 | 6 | 0 | 3 | -20.04 | 50.40 | 15.01 | 211.29 | 0.4704 | -565.0 | -461.2 | |
| 4 | 35 | 2 | 19 | -16.23 | 49.98 | 14.59 | 215.53 | 0.4180 | -1139.6 | -677.2 | |
| 7 | -2 | 4 | -2 | -17.80 | 49.85 | 14.46 | 213.13 | 0.4369 | -1578.3 | 999999 | |
| 2 | -8 | 1 | -8 | -16.65 | 49.75 | 14.37 | 214.52 | 0.4213 | -1145.0 | 999999 | |
| 0 | 7 | 0 | 4 | -19.64 | 49.88 | 14.49 | 210.88 | 0.4611 | -718.0 | -606.5 | |
| 0 | 3 | 0 | 2 | -20.29 | 49.81 | 14.42 | 210.01 | 0.4690 | -814.0 | -607.8 | |
| 3 | -2 | 2 | -2 | -18.65 | 49.49 | 14.10 | 211.40 | 0.4449 | -1171.0 | 999999 | |
| 4 | -2 | 2 | -2 | -17.88 | 49.42 | 14.04 | 212.26 | 0.4343 | -1480.3 | 999999 | |
| 0 | 8 | 0 | 4 | -16.59 | 48.56 | 13.17 | 212.34 | 0.4100 | 699.0 | 705.6 | |
| 0 | 6 | 0 | 3 | -16.08 | 48.52 | 13.14 | 212.97 | 0.4030 | 773.0 | 669.5 | |
| 0 | 20 | 0 | 11 | -17.05 | 48.21 | 12.82 | 211.04 | 0.4132 | 1004.0 | 923.8 | |
| 8 | 79 | 4 | 43 | -19.57 | 48.10 | 12.71 | 207.79 | 0.4465 | -1270.1 | -749.9 | |
| 6 | 111 | 3 | 61 | -18.06 | 47.68 | 12.30 | 208.75 | 0.4228 | 786.5 | 22.3 | |
| 4 | -19 | 2 | -19 | -17.67 | 47.36 | 11.97 | 208.57 | 0.4150 | 1304.4 | 999999 | |
| 0 | 4 | 0 | 2 | -16.74 | 47.17 | 11.78 | 209.36 | 0.4006 | 621.0 | 640.8 | |
| 0 | 2 | 0 | 1 | -19.69 | 47.33 | 11.95 | 206.24 | 0.4427 | 33.0 | -121.7 | |
| 0 | 13 | 0 | 7 | -20.81 | 47.12 | 11.73 | 204.69 | 0.4569 | 756.0 | 620.7 | |
| 9 | 17 | 5 | 9 | -16.78 | 46.75 | 11.36 | 208.44 | 0.3979 | 1515.5 | 985.1 | |
| 0 | 4 | 0 | 2 | -17.28 | 46.70 | 11.31 | 207.70 | 0.4046 | 866.0 | 633.4 | |
| 0 | 4 | 0 | 2 | -20.15 | 46.68 | 11.29 | 204.52 | 0.4448 | 729.0 | 536.3 | |
| 0 | 3 | 0 | 2 | -19.07 | 46.47 | 11.09 | 205.23 | 0.4282 | 785.0 | 755.2 | |
| 9 | 29 | 5 | 16 | -20.49 | 46.06 | 10.67 | 203.01 | 0.4457 | 1324.6 | 907.2 | |
| 0 | 7 | 0 | 4 | -19.28 | 45.80 | 10.42 | 203.68 | 0.4268 | 1053.0 | 933.2 | |
| 4 | -28 | 2 | -28 | -20.71 | 45.86 | 10.47 | 202.42 | 0.4476 | 1419.8 | 999999 | |
| 0 | 4 | 0 | 2 | -19.62 | 45.61 | 10.23 | 202.96 | 0.4305 | 840.0 | 802.6 | |
| 0 | 8 | 0 | 4 | -17.90 | 45.38 | 10.00 | 204.23 | 0.4042 | 773.0 | 600.6 | |
| 0 | 4 | 0 | 2 | -19.27 | 45.42 | 10.04 | 202.91 | 0.4243 | 1081.0 | 973.4 | |
| 4 | 14 | 2 | 8 | -20.75 | 45.43 | 10.04 | 201.56 | 0.4456 | 1248.8 | 1013.3 | |
| 0 | 5 | 0 | 3 | -19.96 | 45.08 | 9.69 | 201.57 | 0.4322 | 1089.0 | 915.0 | |
| 0 | 3 | 0 | 2 | -18.11 | 44.51 | 9.12 | 202.13 | 0.4017 | 708.0 | 598.8 | |
| 0 | 8 | 0 | 4 | -19.83 | 44.56 | 9.17 | 200.64 | 0.4273 | 1066.0 | 901.3 | |
| 0 | 21 | 0 | 12 | -20.21 | 44.37 | 8.98 | 199.92 | 0.4319 | 1020.0 | 865.4 | |
| 0 | 7 | 0 | 4 | -18.14 | 44.00 | 8.62 | 200.98 | 0.3993 | 1134.0 | 963.6 | |
| 0 | 13 | 0 | 7 | -21.17 | 44.00 | 8.61 | 198.40 | 0.4441 | 853.0 | 790.1 | |
| 0 | 6 | 0 | 3 | -22.62 | 44.00 | 8.61 | 197.35 | 0.4655 | 630.0 | 475.2 | |
| 0 | 6 | 0 | 3 | -17.89 | 43.61 | 8.22 | 200.35 | 0.3932 | 944.0 | 768.2 | |
| 0 | 5 | 0 | 3 | -20.20 | 43.56 | 8.17 | 198.25 | 0.4276 | 1223.0 | 891.6 | |
| 0 | 4 | 0 | 2 | -22.70 | 43.44 | 8.05 | 196.24 | 0.4642 | 759.0 | 680.8 | |
| 0 | 3 | 0 | 2 | -22.01 | 39.32 | 3.93 | 188.34 | 0.4399 | 787.0 | 693.7 | |
| 0 | 6 | 0 | 3 | -22.13 | 37.69 | 2.31 | 184.90 | 0.4389 | 925.0 | 770.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
