SOHO MDI 2000-07-09 15:59:31 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 172 | 953 | 98 | 542 | -17.72 | 31.31 | 19.76 | 220.94 | 0.4896 | 183.6 | 93.7 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2000-07-09 15:59:31 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0 | 3 | 0 | 2 | -14.78 | 41.31 | 29.75 | 237.03 | 0.5741 | -769.0 | -616.2 | |
| 0 | 6 | 0 | 4 | -13.09 | 39.17 | 27.61 | 237.81 | 0.5356 | -574.0 | -462.1 | |
| 6 | 307 | 3 | 181 | -18.22 | 36.85 | 25.29 | 227.65 | 0.5513 | -1362.4 | -518.3 | |
| 0 | 3 | 0 | 2 | -16.00 | 36.25 | 24.70 | 230.26 | 0.5245 | -753.0 | -609.8 | |
| 30 | -3 | 18 | -3 | -18.55 | 36.53 | 24.98 | 226.83 | 0.5510 | -1648.9 | 999999 | |
| 12 | -3 | 7 | -3 | -17.85 | 35.78 | 24.23 | 226.99 | 0.5363 | -1485.2 | 999999 | |
| 4 | -3 | 2 | -3 | -17.62 | 35.39 | 23.83 | 226.85 | 0.5299 | -1530.8 | 999999 | |
| 0 | 3 | 0 | 2 | -19.84 | 34.85 | 23.29 | 223.14 | 0.5461 | -450.0 | -465.6 | |
| 0 | 7 | 0 | 4 | -17.33 | 34.13 | 22.57 | 225.76 | 0.5135 | -869.0 | -771.2 | |
| 0 | 3 | 0 | 2 | -19.78 | 34.47 | 22.92 | 222.76 | 0.5418 | -759.0 | -601.4 | |
| 0 | 2 | 0 | 1 | -19.21 | 34.07 | 22.51 | 223.04 | 0.5319 | -733.0 | -627.2 | |
| 0 | 3 | 0 | 2 | -17.32 | 33.76 | 22.21 | 225.32 | 0.5095 | -605.0 | -602.0 | |
| 5 | 12 | 3 | 7 | -17.40 | 33.37 | 21.82 | 224.72 | 0.5061 | -1200.9 | -748.1 | |
| 0 | 3 | 0 | 1 | -17.64 | 33.00 | 21.45 | 223.88 | 0.5047 | -481.0 | -405.2 | |
| 0 | 4 | 0 | 2 | -18.07 | 32.92 | 21.37 | 223.17 | 0.5083 | -5.0 | 114.5 | |
| 0 | 10 | 0 | 6 | -18.58 | 32.81 | 21.25 | 222.30 | 0.5125 | 470.0 | 619.2 | |
| 5 | 20 | 3 | 12 | -17.76 | 32.57 | 21.01 | 223.14 | 0.5014 | -1095.0 | -976.4 | |
| 2 | 8 | 1 | 5 | -16.86 | 32.24 | 20.68 | 224.01 | 0.4885 | -910.0 | -755.2 | |
| 2 | 29 | 1 | 16 | -17.75 | 32.03 | 20.48 | 222.44 | 0.4958 | -1119.8 | -849.0 | |
| 7 | -19 | 4 | -19 | -17.56 | 31.61 | 20.06 | 222.12 | 0.4895 | -1135.7 | 999999 | |
| 2 | 9 | 1 | 5 | -18.45 | 31.14 | 19.59 | 220.21 | 0.4945 | -1148.1 | -770.3 | |
| 4 | 15 | 2 | 8 | -19.32 | 29.96 | 18.41 | 217.33 | 0.4933 | -1087.5 | -657.6 | |
| 0 | 3 | 0 | 2 | -18.12 | 29.65 | 18.09 | 218.48 | 0.4763 | -861.0 | -613.5 | |
| 5 | 388 | 3 | 214 | -16.61 | 28.89 | 17.33 | 219.44 | 0.4513 | 1051.5 | 809.0 | |
| 0 | 2 | 0 | 1 | -18.57 | 28.82 | 17.27 | 216.60 | 0.4739 | 400.0 | 329.2 | |
| 0 | 9 | 0 | 5 | -19.21 | 28.89 | 17.33 | 215.86 | 0.4823 | -657.0 | -497.7 | |
| 5 | -24 | 3 | -24 | -17.49 | 28.45 | 16.90 | 217.47 | 0.4575 | 1035.1 | 999999 | |
| 0 | 15 | 0 | 8 | -18.13 | 28.51 | 16.96 | 216.69 | 0.4658 | 911.0 | 697.0 | |
| 7 | -24 | 4 | -24 | -16.98 | 28.18 | 16.63 | 217.77 | 0.4488 | 1207.6 | 999999 | |
| 0 | 5 | 0 | 3 | -18.60 | 28.17 | 16.61 | 215.52 | 0.4683 | 713.0 | 649.1 | |
| 34 | -24 | 19 | -24 | -17.14 | 27.68 | 16.13 | 216.70 | 0.4459 | 2107.3 | 999999 | |
| 16 | -24 | 9 | -24 | -17.39 | 27.40 | 15.85 | 215.88 | 0.4464 | 1561.6 | 999999 | |
| -31 | -24 | -31 | -24 | -16.88 | 27.31 | 15.76 | 216.45 | 0.4393 | 999999 | 999999 | |
| 16 | 84 | 9 | 47 | -18.41 | 27.32 | 15.77 | 214.38 | 0.4585 | 1193.2 | 394.9 | |
| -31 | -24 | -31 | -24 | -16.74 | 26.87 | 15.32 | 215.87 | 0.4335 | 999999 | 999999 | |
| 10 | -34 | 6 | -34 | -18.31 | 26.62 | 15.07 | 213.32 | 0.4511 | 1278.2 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
