SOHO MDI 2000-07-09 22:23:31 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 193 | 993 | 113 | 576 | -17.69 | 30.78 | 22.76 | 224.96 | 0.5201 | 224.3 | 134.5 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2000-07-09 22:23:31 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0 | 4 | 0 | 2 | -14.72 | 41.38 | 33.36 | 239.88 | 0.6171 | -606.0 | -447.4 | |
| 0 | 5 | 0 | 3 | -14.98 | 39.43 | 31.41 | 238.04 | 0.5955 | -977.0 | -793.2 | |
| 0 | 2 | 0 | 2 | -15.69 | 39.21 | 31.19 | 236.84 | 0.5978 | -641.0 | -563.0 | |
| 6 | 248 | 4 | 152 | -18.28 | 37.18 | 29.16 | 231.40 | 0.5942 | -1282.2 | -509.4 | |
| 27 | -4 | 17 | -4 | -18.66 | 36.96 | 28.94 | 230.68 | 0.5949 | -1453.7 | 999999 | |
| -5 | -4 | -5 | -4 | -18.39 | 36.68 | 28.65 | 230.77 | 0.5896 | 999999 | 999999 | |
| 10 | -4 | 6 | -4 | -18.00 | 36.37 | 28.34 | 231.03 | 0.5829 | -1503.2 | 999999 | |
| 5 | -4 | 3 | -4 | -17.77 | 36.04 | 28.02 | 231.04 | 0.5775 | -1428.3 | 999999 | |
| 0 | 4 | 0 | 2 | -17.84 | 35.59 | 27.56 | 230.50 | 0.5730 | -1015.0 | -731.3 | |
| 4 | 10 | 2 | 6 | -17.35 | 34.76 | 26.73 | 230.38 | 0.5596 | -1089.0 | -810.8 | |
| 3 | 58 | 2 | 34 | -17.31 | 33.73 | 25.71 | 229.36 | 0.5479 | -1032.6 | -804.2 | |
| 3 | -11 | 2 | -11 | -17.25 | 33.13 | 25.10 | 228.79 | 0.5406 | -1372.0 | 999999 | |
| 11 | -11 | 6 | -11 | -17.51 | 33.03 | 25.00 | 228.32 | 0.5418 | -1393.5 | 999999 | |
| 3 | -11 | 2 | -11 | -17.89 | 32.99 | 24.97 | 227.73 | 0.5450 | -130.6 | 999999 | |
| 2 | 7 | 1 | 4 | -16.73 | 32.59 | 24.57 | 228.98 | 0.5299 | -843.5 | -600.1 | |
| 0 | 4 | 0 | 2 | -18.09 | 32.61 | 24.58 | 227.01 | 0.5427 | -598.0 | -441.8 | |
| 0 | 5 | 0 | 3 | -18.90 | 32.50 | 24.48 | 225.76 | 0.5493 | 568.0 | 520.9 | |
| 0 | 8 | 0 | 5 | -17.65 | 32.32 | 24.29 | 227.30 | 0.5355 | -872.0 | -756.1 | |
| 5 | 14 | 3 | 8 | -18.97 | 32.01 | 23.98 | 225.10 | 0.5448 | 810.8 | 414.7 | |
| 0 | 3 | 0 | 2 | -17.08 | 31.64 | 23.62 | 227.36 | 0.5227 | 321.0 | 226.8 | |
| 0 | 12 | 0 | 7 | -17.64 | 31.68 | 23.65 | 226.59 | 0.5284 | -992.0 | -895.3 | |
| 0 | 7 | 0 | 4 | -18.23 | 31.49 | 23.46 | 225.52 | 0.5321 | -978.0 | -671.4 | |
| 0 | 5 | 0 | 3 | -16.56 | 29.65 | 21.63 | 225.67 | 0.4958 | 464.0 | 264.7 | |
| 5 | 28 | 3 | 16 | -19.38 | 29.79 | 21.77 | 221.84 | 0.5265 | -890.4 | -785.2 | |
| 5 | -24 | 3 | -24 | -19.03 | 29.61 | 21.58 | 222.08 | 0.5210 | -945.7 | 999999 | |
| 0 | 3 | 0 | 2 | -17.70 | 29.39 | 21.36 | 223.65 | 0.5047 | 468.0 | 411.4 | |
| 0 | 3 | 0 | 2 | -16.50 | 28.98 | 20.95 | 224.88 | 0.4879 | 419.0 | 321.8 | |
| 0 | 3 | 0 | 2 | -19.32 | 29.11 | 21.08 | 221.03 | 0.5191 | -834.0 | -691.2 | |
| 5 | 402 | 3 | 226 | -16.75 | 28.52 | 20.49 | 223.89 | 0.4856 | 1025.3 | 793.1 | |
| 0 | 4 | 0 | 2 | -19.05 | 28.71 | 20.69 | 220.87 | 0.5123 | -634.0 | -539.9 | |
| 5 | -29 | 3 | -29 | -17.50 | 28.07 | 20.05 | 222.17 | 0.4890 | 1145.9 | 999999 | |
| 3 | 43 | 2 | 25 | -18.31 | 28.08 | 20.06 | 221.04 | 0.4979 | 927.2 | 418.9 | |
| 8 | -29 | 4 | -29 | -17.15 | 27.90 | 19.88 | 222.43 | 0.4835 | 1168.8 | 999999 | |
| 4 | -32 | 2 | -32 | -18.73 | 27.82 | 19.80 | 220.09 | 0.5001 | 424.9 | 999999 | |
| 3 | -29 | 2 | -29 | -18.00 | 27.64 | 19.62 | 220.86 | 0.4902 | 838.6 | 999999 | |
| 25 | -29 | 14 | -29 | -17.14 | 27.46 | 19.44 | 221.82 | 0.4788 | 1567.6 | 999999 | |
| -36 | -29 | -36 | -29 | -17.31 | 27.17 | 19.15 | 221.16 | 0.4777 | 999999 | 999999 | |
| 0 | 4 | 0 | 2 | -19.06 | 27.33 | 19.30 | 218.95 | 0.4990 | 368.0 | 307.8 | |
| 11 | 96 | 6 | 54 | -18.41 | 27.21 | 19.18 | 219.65 | 0.4905 | 1022.9 | 424.0 | |
| 28 | -29 | 16 | -29 | -16.75 | 26.98 | 18.96 | 221.70 | 0.4696 | 2187.3 | 999999 | |
| 12 | -39 | 7 | -39 | -18.23 | 26.48 | 18.46 | 218.85 | 0.4814 | 1573.1 | 999999 | |
| 0 | 4 | 0 | 2 | -14.21 | 25.92 | 17.90 | 224.08 | 0.4301 | 746.0 | 526.0 | |
| 0 | 7 | 0 | 4 | -15.49 | 25.43 | 17.40 | 221.21 | 0.4393 | 592.0 | 539.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
