SOHO MDI 2000-07-11 23:59:31 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0 | 47 | 0 | 24 | 14.43 | 347.53 | 6.87 | 328.14 | 0.2195 | -499.0 | -512.5 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2000-07-11 23:59:31 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0 | 3 | 0 | 2 | 15.30 | 357.14 | 16.48 | 305.73 | 0.3385 | 943.0 | 912.4 | |
| 0 | 13 | 0 | 7 | 13.42 | 348.09 | 7.43 | 322.23 | 0.2062 | -846.0 | -650.7 | |
| 0 | 2 | 0 | 1 | 19.91 | 348.18 | 7.52 | 335.74 | 0.3006 | 729.0 | 563.4 | |
| 0 | 9 | 0 | 4 | 13.14 | 347.50 | 6.84 | 323.60 | 0.1965 | -1159.0 | -882.0 | |
| 0 | 4 | 0 | 2 | 14.71 | 347.51 | 6.85 | 327.97 | 0.2185 | -976.0 | -743.0 | |
| 0 | 4 | 0 | 2 | 13.39 | 346.94 | 6.28 | 326.64 | 0.1943 | -1070.0 | -804.5 | |
| 0 | 4 | 0 | 2 | 13.40 | 344.00 | 3.34 | 340.68 | 0.1720 | -922.0 | -773.8 | |
| 0 | 8 | 0 | 4 | 16.59 | 343.68 | 3.02 | 346.87 | 0.2230 | -691.0 | -490.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
