SOHO MDI 2000-07-12 19:11:31 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 95 | 578 | 75 | 447 | -20.46 | 14.43 | 44.36 | 238.54 | 0.7681 | 322.0 | 147.1 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2000-07-12 19:11:31 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 12 | 108 | 11 | 94 | -19.43 | 20.96 | 50.89 | 242.85 | 0.8245 | -641.8 | -182.9 | |
| 0 | 2 | 0 | 2 | -17.90 | 19.55 | 49.48 | 244.07 | 0.8065 | -568.0 | -478.9 | |
| 20 | 70 | 17 | 58 | -19.42 | 18.48 | 48.41 | 241.86 | 0.8021 | -963.7 | -478.5 | |
| 4 | 22 | 3 | 18 | -20.68 | 16.48 | 46.41 | 239.48 | 0.7888 | -591.9 | -688.6 | |
| 0 | 3 | 0 | 2 | -20.74 | 15.89 | 45.82 | 239.14 | 0.7836 | -683.0 | -640.8 | |
| 0 | 12 | 0 | 9 | -20.47 | 15.78 | 45.71 | 239.40 | 0.7814 | -777.0 | -649.3 | |
| 0 | 3 | 0 | 3 | -20.19 | 13.83 | 43.76 | 238.76 | 0.7615 | 472.0 | 402.1 | |
| 4 | 331 | 3 | 242 | -20.80 | 12.25 | 42.18 | 237.18 | 0.7492 | 425.1 | 502.7 | |
| 0 | 4 | 0 | 3 | -20.09 | 11.78 | 41.71 | 237.78 | 0.7409 | 350.0 | 346.3 | |
| 0 | 3 | 0 | 2 | -18.05 | 10.60 | 40.53 | 239.64 | 0.7184 | 443.0 | 409.2 | |
| 40 | -8 | 29 | -8 | -20.74 | 11.09 | 41.02 | 236.59 | 0.7376 | 1153.1 | 999999 | |
| -11 | -8 | -11 | -8 | -21.67 | 11.35 | 41.28 | 235.63 | 0.7451 | 999999 | 999999 | |
| -11 | -8 | -11 | -8 | -21.23 | 11.14 | 41.07 | 236.04 | 0.7406 | 999999 | 999999 | |
| 2 | 15 | 2 | 11 | -19.68 | 10.64 | 40.57 | 237.63 | 0.7274 | 208.1 | 468.6 | |
| 4 | -8 | 3 | -8 | -21.15 | 10.55 | 40.48 | 235.78 | 0.7345 | 1276.0 | 999999 | |
| 9 | -8 | 7 | -8 | -21.12 | 9.93 | 39.86 | 235.44 | 0.7282 | 1557.9 | 999999 | |
| 0 | 5 | 0 | 3 | -22.05 | 6.42 | 36.35 | 232.01 | 0.6993 | 525.0 | 440.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
