SOHO MDI 2000-07-18 06:23:31 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 51 | 499 | 31 | 299 | 19.09 | 289.25 | 31.55 | 297.83 | 0.5607 | 306.0 | 170.5 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2000-07-18 06:23:31 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0 | 7 | 0 | 4 | 21.73 | 292.14 | 34.45 | 300.22 | 0.6103 | 688.0 | 575.5 | |
| 15 | 298 | 9 | 182 | 18.44 | 291.12 | 33.43 | 295.57 | 0.5815 | 1504.5 | 673.9 | |
| 11 | -2 | 7 | -2 | 19.34 | 291.17 | 33.48 | 297.00 | 0.5864 | 1202.7 | 999999 | |
| 5 | -2 | 3 | -2 | 18.81 | 290.95 | 33.26 | 296.27 | 0.5811 | 1501.6 | 999999 | |
| 0 | 6 | 0 | 4 | 19.05 | 289.27 | 31.58 | 297.62 | 0.5608 | 422.0 | 484.5 | |
| 3 | 8 | 2 | 5 | 18.93 | 288.17 | 30.47 | 298.11 | 0.5460 | -435.9 | -339.1 | |
| 0 | 2 | 0 | 1 | 20.13 | 287.98 | 30.29 | 300.26 | 0.5504 | 428.0 | 336.8 | |
| 0 | 26 | 0 | 15 | 20.96 | 286.89 | 29.20 | 302.42 | 0.5418 | -571.0 | -633.5 | |
| 17 | 133 | 10 | 77 | 18.98 | 285.83 | 28.13 | 299.82 | 0.5159 | -1549.4 | -771.3 | |
| 0 | 6 | 0 | 3 | 20.19 | 285.39 | 27.69 | 302.28 | 0.5180 | -868.0 | -717.3 | |
| 0 | 9 | 0 | 5 | 20.81 | 285.32 | 27.63 | 303.41 | 0.5213 | -382.0 | -383.9 | |
| 0 | 4 | 0 | 3 | 21.09 | 284.37 | 26.68 | 304.70 | 0.5116 | -640.0 | -533.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
