SOHO MDI 2000-08-30 06:23:31 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 20 | 144 | 12 | 86 | -9.54 | 20.62 | -28.20 | 120.42 | 0.5425 | -883.4 | -555.6 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2000-08-30 06:23:31 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0 | 6 | 0 | 4 | -13.04 | 23.47 | -25.35 | 128.69 | 0.5364 | -692.0 | -575.4 | |
| 8 | 86 | 5 | 50 | -8.93 | 21.68 | -27.14 | 120.37 | 0.5244 | -1403.1 | -823.6 | |
| 9 | -2 | 5 | -2 | -8.67 | 21.25 | -27.57 | 119.54 | 0.5279 | -1190.0 | 999999 | |
| 0 | 9 | 0 | 5 | -10.20 | 21.08 | -27.75 | 121.85 | 0.5415 | -529.0 | -436.3 | |
| 0 | 3 | 0 | 2 | -11.32 | 20.96 | -27.86 | 123.49 | 0.5515 | -334.0 | -244.9 | |
| 0 | 14 | 0 | 8 | -10.84 | 20.65 | -28.17 | 122.46 | 0.5517 | -709.0 | -525.9 | |
| 0 | 3 | 0 | 2 | -8.62 | 20.72 | -28.10 | 118.97 | 0.5345 | -344.0 | -336.7 | |
| 0 | 4 | 0 | 2 | -12.77 | 20.25 | -28.57 | 124.99 | 0.5715 | -690.0 | -555.5 | |
| 0 | 4 | 0 | 3 | -12.06 | 16.55 | -32.27 | 120.76 | 0.6098 | -658.0 | -552.7 | |
| 0 | 6 | 0 | 4 | -9.07 | 16.34 | -32.48 | 116.18 | 0.5931 | 667.0 | 541.7 | |
| 3 | 9 | 2 | 6 | -8.72 | 16.09 | -32.73 | 115.46 | 0.5941 | 804.2 | 642.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
