SOHO MDI 2000-09-01 07:59:31 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 26 | 152 | 13 | 79 | -9.09 | 21.74 | 0.23 | 180.89 | 0.2827 | -1298.4 | -641.9 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2000-09-01 07:59:31 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0 | 5 | 0 | 3 | -10.49 | 22.99 | 1.48 | 184.77 | 0.3065 | 566.0 | 541.0 | |
| 12 | 122 | 6 | 63 | -8.73 | 22.39 | 0.87 | 183.14 | 0.2763 | -1606.5 | -789.9 | |
| 5 | -2 | 2 | -2 | -9.13 | 22.11 | 0.60 | 182.09 | 0.2830 | -1292.8 | 999999 | |
| 9 | -2 | 5 | -2 | -8.97 | 21.71 | 0.20 | 180.71 | 0.2800 | -1233.0 | 999999 | |
| 0 | 6 | 0 | 3 | -9.83 | 21.71 | 0.20 | 180.67 | 0.2945 | -767.0 | -573.5 | |
| 0 | 5 | 0 | 3 | -10.12 | 21.19 | -0.32 | 178.95 | 0.2993 | -627.0 | -503.9 | |
| 0 | 4 | 0 | 2 | -7.46 | 20.40 | -1.11 | 175.68 | 0.2553 | 675.0 | 516.0 | |
| 0 | 6 | 0 | 3 | -10.71 | 18.23 | -3.28 | 169.65 | 0.3140 | -506.0 | -453.3 | |
| 0 | 4 | 0 | 2 | -10.02 | 16.60 | -4.91 | 164.11 | 0.3090 | 418.0 | 493.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
