SOHO MDI 2000-09-03 22:23:31 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4 | 134 | 2 | 67 | 7.93 | 342.44 | -4.72 | 95.69 | 0.0947 | 271.2 | -177.9 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2000-09-03 22:23:31 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0 | 6 | 0 | 3 | 4.38 | 349.82 | 2.66 | 222.86 | 0.0684 | 897.0 | 755.0 | |
| 0 | 18 | 0 | 9 | 6.27 | 346.67 | -0.49 | 153.73 | 0.0191 | -1140.0 | -928.9 | |
| 0 | 5 | 0 | 2 | 8.15 | 346.16 | -1.00 | 47.66 | 0.0235 | 447.0 | 318.3 | |
| 0 | 3 | 0 | 2 | 7.39 | 344.02 | -3.14 | 87.07 | 0.0546 | -628.0 | -542.8 | |
| 0 | 14 | 0 | 7 | 6.28 | 342.68 | -4.47 | 101.93 | 0.0796 | -1078.0 | -821.1 | |
| 0 | 4 | 0 | 2 | 3.26 | 342.39 | -4.77 | 129.76 | 0.1085 | -557.0 | -445.5 | |
| 0 | 11 | 0 | 5 | 9.96 | 342.04 | -5.11 | 61.36 | 0.1005 | 840.0 | 658.9 | |
| 4 | 10 | 2 | 5 | 9.13 | 341.26 | -5.90 | 71.70 | 0.1074 | 937.0 | 682.1 | |
| 0 | 24 | 0 | 12 | 9.72 | 341.13 | -6.03 | 67.05 | 0.1130 | 1083.0 | 756.0 | |
| 0 | 7 | 0 | 4 | 4.15 | 341.08 | -6.08 | 116.80 | 0.1189 | -618.0 | -583.3 | |
| 0 | 11 | 0 | 5 | 7.71 | 340.84 | -6.32 | 85.31 | 0.1099 | -665.0 | -571.4 | |
| 0 | 12 | 0 | 6 | 10.68 | 339.58 | -7.58 | 64.81 | 0.1438 | -1240.0 | -902.5 | |
| 0 | 9 | 0 | 5 | 9.72 | 338.76 | -8.40 | 72.81 | 0.1514 | -744.0 | -781.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
