group	Proj. U	Proj. WS	Corr. U	Corr. WS	B	L	LCM	Pos. angle	r	MU	MP
9169	405	3586	247	2181	9.86	79.95	35.58	277.42	0.5797	1163.6	366.7

previous   or   next   observation for the same group / back to the solar disc SOHO MDI 2000-09-26 20:47:31 UT

spot	Proj. U	Proj. WS	Corr. U	Corr. WS	B	L	LCM	Pos. angle	r	MU	MP
1	4	10	3	7	7.96	86.28	41.91	274.26	0.6657	741.5	485.9
2	0	4	0	3	6.83	85.10	40.73	272.49	0.6508	659.0	561.3
3	45	2904	29	1784	9.66	84.57	40.20	276.85	0.6432	1369.6	530.6
4	5	20	3	13	8.08	83.14	38.76	274.35	0.6240	729.1	498.8
5	13	44	8	28	7.11	82.99	38.61	272.79	0.6222	239.0	-103.3
6	72	-3	45	-3	9.95	82.72	38.34	277.38	0.6184	1466.9	999999
7	0	4	0	3	7.35	82.36	37.98	273.15	0.6136	-240.0	-171.0
8	-6	-3	-6	-3	9.89	81.91	37.53	277.32	0.6073	999999	999999
9	0	5	0	3	12.83	82.01	37.64	282.14	0.6113	-9.0	31.9
10	14	-3	8	-3	11.44	81.68	37.30	279.90	0.6053	994.3	999999
11	16	-3	10	-3	9.03	81.30	36.93	275.92	0.5988	1128.6	999999
12	0	6	0	4	6.99	80.94	36.56	272.46	0.5941	-559.0	-483.1
13	17	-3	10	-3	9.49	80.91	36.54	276.70	0.5935	1367.5	999999
14	9	-3	5	-3	8.10	80.75	36.38	274.33	0.5911	379.1	999999
15	9	-3	5	-3	10.59	80.91	36.53	278.55	0.5940	892.1	999999
16	28	-3	17	-3	8.93	80.50	36.13	275.76	0.5876	1562.4	999999
17	9	-3	5	-3	10.01	80.19	35.82	277.62	0.5837	1022.2	999999
18	9	-3	6	-3	11.22	80.26	35.88	279.69	0.5855	936.7	999999
19	4	-3	3	-3	10.27	79.93	35.56	278.08	0.5802	910.0	999999
20	25	-3	15	-3	9.49	79.79	35.41	276.74	0.5777	1711.6	999999
21	46	-3	28	-3	10.11	79.38	35.00	277.84	0.5722	1727.3	999999
22	0	5	0	3	14.08	79.98	35.61	284.60	0.5858	322.0	437.4
23	0	2	0	1	7.90	79.04	34.66	273.96	0.5669	833.0	798.9
24	0	41	0	25	13.31	79.60	35.23	283.38	0.5792	991.0	612.8
25	9	-3	6	-3	9.08	78.87	34.50	276.07	0.5646	1204.3	999999
26	18	-3	11	-3	10.45	78.89	34.52	278.49	0.5656	1918.7	999999
27	0	12	0	7	7.94	78.52	34.14	274.02	0.5594	1025.0	864.2
28	11	-3	6	-3	10.02	78.40	34.03	277.76	0.5584	1862.2	999999
29	9	-3	5	-3	8.43	77.47	33.10	274.92	0.5443	488.8	999999
30	3	59	2	35	11.84	77.45	33.07	281.19	0.5466	1148.4	588.0
31	0	7	0	4	16.06	78.14	33.77	288.54	0.5655	653.0	581.4
32	0	3	0	2	13.21	77.60	33.22	283.64	0.5510	720.0	534.6
33	0	5	0	3	11.40	76.96	32.59	280.46	0.5390	473.0	466.0
34	0	4	0	3	14.49	77.37	33.00	286.00	0.5507	-340.0	-212.3
35	4	12	2	7	16.18	77.48	33.11	288.98	0.5569	-515.5	-375.6
36	9	-3	5	-3	9.95	76.46	32.08	277.80	0.5302	1513.6	999999
37	0	17	0	10	15.42	76.29	31.91	288.06	0.5381	-1043.0	-778.6
38	4	-3	2	-3	8.76	74.77	30.39	275.62	0.5045	-936.6	999999
39	0	6	0	3	10.21	74.73	30.35	278.51	0.5049	-266.0	-264.3
40	0	6	0	3	10.81	74.42	30.05	279.76	0.5011	-634.0	-531.5
41	0	3	0	1	10.54	74.39	30.02	279.22	0.5003	-661.0	-692.9
42	0	8	0	5	13.27	74.73	30.36	284.52	0.5102	-298.0	-494.8
43	0	6	0	3	10.12	74.26	29.88	278.39	0.4978	-854.0	-707.0
44	3	26	2	15	8.37	74.05	29.68	274.87	0.4936	-919.1	-364.7
45	0	8	0	4	7.99	73.88	29.51	274.10	0.4910	-341.0	-441.7
46	0	4	0	3	11.14	74.14	29.77	280.47	0.4974	-799.0	-680.0
47	0	5	0	3	11.57	74.14	29.77	281.33	0.4981	-744.0	-658.4
48	0	7	0	4	9.36	73.87	29.49	276.89	0.4913	-726.0	-708.8
49	0	5	0	3	13.37	74.28	29.91	284.87	0.5039	-785.0	-675.9
50	0	5	0	3	13.89	74.26	29.89	285.88	0.5049	-578.0	-523.9
51	0	8	0	4	10.65	73.81	29.44	279.54	0.4918	-1131.0	-973.6
52	4	100	3	56	9.07	73.52	29.15	276.32	0.4859	-1169.4	-987.0
53	0	13	0	8	11.14	73.50	29.13	280.59	0.4878	-1159.0	-987.2
54	0	13	0	7	10.73	73.23	28.85	279.79	0.4832	-1386.0	-1061.2
55	0	13	0	7	7.93	72.98	28.60	273.97	0.4773	-903.0	-706.3
56	0	3	0	2	13.07	73.37	28.99	284.56	0.4898	-906.0	-766.6
57	0	10	0	5	7.51	72.77	28.39	273.09	0.4741	-848.0	-785.4
58	0	3	0	2	11.94	73.18	28.81	282.31	0.4845	-893.0	-815.6
59	0	14	0	8	7.25	72.53	28.15	272.53	0.4704	-922.0	-798.0
60	0	4	0	2	9.28	72.46	28.09	276.87	0.4699	-918.0	-870.3
61	6	-52	3	-52	8.47	72.35	27.97	275.14	0.4678	-1416.8	999999
62	0	4	0	2	11.93	72.68	28.31	282.43	0.4771	-1028.0	-890.7
63	0	19	0	11	7.08	71.98	27.61	272.15	0.4621	-1002.0	-969.1
64	0	6	0	3	9.66	71.96	27.58	277.75	0.4626	-753.0	-807.7
65	0	12	0	7	12.43	72.20	27.82	283.61	0.4709	-996.0	-902.0
66	0	12	0	7	7.07	71.54	27.16	272.10	0.4553	-1076.0	-809.5
67	0	4	0	2	7.73	71.58	27.21	273.55	0.4558	-1090.0	-980.5
68	0	12	0	7	9.52	71.63	27.26	277.49	0.4575	-804.0	-793.3
69	0	9	0	5	10.11	71.60	27.22	278.79	0.4576	-587.0	-563.8
70	0	7	0	4	7.47	71.34	26.97	272.98	0.4522	-1128.0	-1001.8
71	0	9	0	5	8.84	71.31	26.94	276.02	0.4520	-998.0	-858.1
72	0	7	0	4	6.80	70.73	26.36	271.45	0.4428	-1064.0	-895.2
73	0	5	0	3	6.49	70.62	26.25	270.74	0.4413	-893.0	-754.7
74	0	11	0	6	14.54	70.97	26.60	288.59	0.4591	-970.0	-805.0
75	0	11	0	6	14.29	70.53	26.16	288.26	0.4518	-1221.0	-1037.3
76	0	15	0	8	15.46	70.69	26.31	290.69	0.4586	-846.0	-684.3
77	0	5	0	3	14.15	70.07	25.70	288.20	0.4444	-948.0	-681.7
78	0	4	0	2	2.20	67.63	23.26	259.69	0.4028	-626.0	-517.6

	Proj. U	-  Projected umbra area in millionths of solar disc, negative values indicate
	that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2.
	Proj. WS	-  Projected whole spot area in millionths of solar disc, negative values indicate
	that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7.
	Corr. U	-  Corrected umbra area in millionths of solar hemisphere, for negative values see above
	Corr. WS	-  Corrected whole spot area in millionths of solar hemisphere, for negative values see above
	B	-  Heliographic latitude B; positive: North, negative: South
	L	-  Heliographic longitude L
	LCM	-  Longitudinal distance from the Sun's central meridian
	Pos. angle	-  Position angle
	r	-  Distance from the centre of Sun's disc in terms of Sun's radius
	MU	-  Mean magnetic field within the umbra contour averaged the pixel values with sign.
	MP	-  Mean magnetic field within the penumbra contour averaged the pixel values with sign.
