SOHO MDI 2000-09-27 17:52:31 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 29 | 199 | 15 | 108 | -13.33 | 24.87 | -7.92 | 159.26 | 0.3723 | -1542.7 | -499.6 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2000-09-27 17:52:31 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0 | 3 | 0 | 2 | -11.49 | 29.05 | -3.74 | 168.50 | 0.3220 | -673.0 | -727.4 | |
| 0 | 7 | 0 | 4 | -11.78 | 28.80 | -3.98 | 167.97 | 0.3275 | -964.0 | -937.3 | |
| 0 | 4 | 0 | 2 | -12.90 | 28.31 | -4.48 | 167.28 | 0.3473 | -593.0 | -507.7 | |
| 29 | 142 | 15 | 76 | -13.18 | 25.97 | -6.81 | 161.30 | 0.3620 | -1701.6 | -623.3 | |
| -4 | -4 | -4 | -4 | -13.22 | 25.61 | -7.18 | 160.42 | 0.3646 | 999999 | 999999 | |
| 0 | 24 | 0 | 13 | -13.16 | 24.68 | -8.10 | 158.05 | 0.3689 | -730.0 | -481.2 | |
| 0 | 5 | 0 | 3 | -14.33 | 19.11 | -13.67 | 147.37 | 0.4266 | 408.0 | 426.2 | |
| 0 | 6 | 0 | 3 | -14.93 | 17.16 | -15.63 | 144.62 | 0.4515 | 672.0 | 611.8 | |
| 0 | 5 | 0 | 3 | -14.80 | 13.88 | -18.91 | 139.16 | 0.4811 | 765.0 | 562.3 | |
| 0 | 3 | 0 | 2 | -18.61 | 12.16 | -20.62 | 141.69 | 0.5405 | 688.0 | 546.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
