SOHO MDI 2000-10-01 12:47:32 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 104 | 630 | 67 | 407 | -21.71 | 314.65 | -28.16 | 136.67 | 0.6398 | -726.9 | -135.9 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2000-10-01 12:47:32 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0 | 4 | 0 | 2 | -20.55 | 317.66 | -25.15 | 138.32 | 0.6007 | -818.0 | -660.9 | |
| 25 | 335 | 15 | 211 | -21.58 | 317.14 | -25.67 | 138.96 | 0.6156 | -2020.3 | -559.1 | |
| 0 | 5 | 0 | 3 | -23.43 | 316.68 | -26.13 | 140.51 | 0.6378 | -474.0 | -345.1 | |
| 34 | -2 | 22 | -2 | -22.04 | 316.87 | -25.94 | 139.18 | 0.6226 | -1287.9 | 999999 | |
| 2 | 13 | 1 | 8 | -19.81 | 316.87 | -25.94 | 136.57 | 0.6009 | 479.7 | 285.6 | |
| 0 | 6 | 0 | 4 | -23.78 | 315.26 | -27.54 | 139.45 | 0.6532 | -517.0 | -412.4 | |
| 0 | 4 | 0 | 3 | -20.56 | 315.90 | -26.91 | 136.44 | 0.6172 | -394.0 | -405.7 | |
| 0 | 3 | 0 | 2 | -20.42 | 315.27 | -27.54 | 135.63 | 0.6219 | -533.0 | -528.5 | |
| 0 | 2 | 0 | 1 | -19.42 | 315.37 | -27.44 | 134.51 | 0.6118 | 496.0 | 397.0 | |
| 0 | 4 | 0 | 3 | -20.26 | 314.97 | -27.84 | 135.14 | 0.6233 | -363.0 | -320.8 | |
| 0 | 3 | 0 | 2 | -21.23 | 314.16 | -28.65 | 135.48 | 0.6397 | -219.0 | -322.0 | |
| 16 | 72 | 10 | 47 | -21.78 | 313.75 | -29.06 | 135.73 | 0.6484 | -1017.1 | -180.9 | |
| 0 | 5 | 0 | 3 | -20.03 | 313.70 | -29.11 | 133.61 | 0.6336 | -613.0 | -385.6 | |
| 0 | 3 | 0 | 2 | -21.35 | 312.79 | -30.02 | 134.33 | 0.6537 | 699.0 | 548.1 | |
| 0 | 12 | 0 | 8 | -20.75 | 312.73 | -30.08 | 133.56 | 0.6491 | 480.0 | 618.4 | |
| 0 | 4 | 0 | 3 | -20.55 | 312.44 | -30.37 | 133.05 | 0.6502 | 646.0 | 609.8 | |
| 6 | 31 | 4 | 21 | -21.93 | 311.97 | -30.84 | 134.26 | 0.6663 | 1011.1 | 741.2 | |
| 5 | 11 | 4 | 7 | -20.79 | 312.00 | -30.81 | 132.94 | 0.6565 | 874.4 | 643.8 | |
| 0 | 4 | 0 | 3 | -22.13 | 310.94 | -31.87 | 133.58 | 0.6775 | 326.0 | 392.6 | |
| 3 | 47 | 2 | 31 | -20.68 | 310.95 | -31.86 | 131.89 | 0.6657 | 632.5 | 791.1 | |
| 11 | -20 | 8 | -20 | -21.22 | 310.77 | -32.04 | 132.37 | 0.6717 | 878.1 | 999999 | |
| 2 | 19 | 1 | 13 | -22.05 | 310.11 | -32.70 | 132.79 | 0.6845 | 659.0 | 623.8 | |
| 0 | 9 | 0 | 6 | -22.87 | 309.79 | -33.02 | 133.45 | 0.6939 | 148.0 | 359.1 | |
| 0 | 13 | 0 | 9 | -21.28 | 309.86 | -32.95 | 131.68 | 0.6808 | 683.0 | 682.2 | |
| 0 | 3 | 0 | 2 | -21.78 | 309.58 | -33.23 | 132.03 | 0.6874 | 464.0 | 298.3 | |
| 0 | 5 | 0 | 4 | -21.62 | 309.32 | -33.49 | 131.64 | 0.6886 | 602.0 | 353.7 | |
| 0 | 11 | 0 | 8 | -22.96 | 304.88 | -37.93 | 129.81 | 0.7391 | 833.0 | 628.8 | |
| 0 | 2 | 0 | 1 | -23.23 | 302.60 | -40.21 | 128.57 | 0.7611 | 434.0 | 449.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
