SOHO MDI 2000-10-06 07:59:32 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 47 | 351 | 36 | 261 | -9.06 | 325.49 | 46.00 | 251.80 | 0.7495 | -1121.9 | -388.5 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2000-10-06 07:59:32 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 34 | 301 | 26 | 227 | -8.93 | 326.42 | 46.92 | 252.36 | 0.7594 | -1030.6 | -413.1 | |
| 13 | -1 | 10 | -1 | -9.01 | 325.97 | 46.47 | 252.09 | 0.7549 | -1533.3 | 999999 | |
| 0 | 4 | 0 | 3 | -7.92 | 323.84 | 44.34 | 252.68 | 0.7274 | -478.0 | -390.4 | |
| 0 | 4 | 0 | 3 | -8.11 | 321.22 | 41.73 | 251.34 | 0.6978 | -752.0 | -663.7 | |
| 0 | 11 | 0 | 8 | -11.72 | 321.53 | 42.03 | 246.65 | 0.7164 | -944.0 | -716.9 | |
| 0 | 7 | 0 | 5 | -10.01 | 320.34 | 40.84 | 248.34 | 0.6953 | 200.0 | 107.2 | |
| 0 | 8 | 0 | 5 | -11.57 | 320.54 | 41.05 | 246.36 | 0.7046 | -531.0 | -302.3 | |
| 0 | 4 | 0 | 3 | -7.48 | 319.18 | 39.68 | 251.29 | 0.6707 | -661.0 | -415.9 | |
| 0 | 4 | 0 | 2 | -8.56 | 316.89 | 37.39 | 248.59 | 0.6473 | 449.0 | 346.3 | |
| 0 | 5 | 0 | 3 | -9.07 | 316.80 | 37.30 | 247.80 | 0.6487 | 685.0 | 572.8 | |
| 0 | 3 | 0 | 2 | -8.28 | 315.82 | 36.33 | 248.41 | 0.6327 | 641.0 | 548.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
