SOHO MDI 2000-10-30 07:59:32 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 145 | 866 | 86 | 507 | -22.79 | 306.43 | -16.69 | 149.86 | 0.5295 | -1110.5 | -401.1 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2000-10-30 07:59:32 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0 | 8 | 0 | 4 | -23.17 | 318.93 | -4.19 | 171.76 | 0.4704 | -759.0 | -630.6 | |
| 0 | 6 | 0 | 4 | -27.13 | 312.90 | -10.22 | 163.19 | 0.5484 | -669.0 | -524.6 | |
| 0 | 4 | 0 | 2 | -25.78 | 312.97 | -10.15 | 162.48 | 0.5292 | -589.0 | -576.3 | |
| 0 | 4 | 0 | 3 | -27.32 | 312.57 | -10.55 | 162.80 | 0.5523 | -736.0 | -668.2 | |
| 0 | 2 | 0 | 1 | -27.24 | 312.14 | -10.98 | 162.09 | 0.5531 | -800.0 | -713.7 | |
| 0 | 4 | 0 | 2 | -27.42 | 311.81 | -11.31 | 161.71 | 0.5571 | -573.0 | -472.0 | |
| 11 | 25 | 6 | 15 | -23.19 | 309.97 | -13.15 | 155.66 | 0.5094 | -969.1 | -606.3 | |
| 0 | 7 | 0 | 4 | -22.50 | 310.04 | -13.08 | 155.15 | 0.4996 | -1101.0 | -865.1 | |
| 3 | 8 | 2 | 5 | -22.81 | 309.54 | -13.58 | 154.62 | 0.5070 | -838.8 | -631.4 | |
| 10 | 283 | 6 | 163 | -23.45 | 307.78 | -15.34 | 152.47 | 0.5272 | -1170.8 | -645.8 | |
| 3 | -10 | 2 | -10 | -23.42 | 307.52 | -15.60 | 152.05 | 0.5285 | -901.8 | 999999 | |
| 33 | -10 | 19 | -10 | -22.24 | 307.57 | -15.55 | 150.96 | 0.5131 | -1728.0 | 999999 | |
| 0 | 3 | 0 | 2 | -25.64 | 306.79 | -16.33 | 153.05 | 0.5616 | -537.0 | -522.6 | |
| 0 | 3 | 0 | 2 | -23.56 | 306.85 | -16.27 | 151.19 | 0.5351 | -638.0 | -608.6 | |
| 0 | 4 | 0 | 3 | -23.35 | 306.61 | -16.51 | 150.64 | 0.5341 | -756.0 | -614.1 | |
| 0 | 5 | 0 | 3 | -25.25 | 306.09 | -17.03 | 151.73 | 0.5615 | -275.0 | -210.4 | |
| 18 | 325 | 11 | 191 | -23.02 | 306.00 | -17.12 | 149.41 | 0.5345 | -1699.5 | -485.5 | |
| 17 | -17 | 10 | -17 | -23.54 | 305.89 | -17.24 | 149.78 | 0.5418 | -1262.0 | 999999 | |
| 23 | -17 | 13 | -17 | -22.85 | 305.54 | -17.58 | 148.58 | 0.5360 | -1418.4 | 999999 | |
| 0 | 6 | 0 | 3 | -21.60 | 305.61 | -17.51 | 147.32 | 0.5201 | -821.0 | -659.7 | |
| -19 | -17 | -19 | -17 | -23.08 | 305.29 | -17.83 | 148.46 | 0.5407 | 999999 | 999999 | |
| 5 | -17 | 3 | -17 | -22.39 | 305.21 | -17.91 | 147.60 | 0.5329 | -1222.3 | 999999 | |
| 0 | 7 | 0 | 4 | -21.10 | 305.29 | -17.83 | 146.27 | 0.5167 | 618.0 | 435.2 | |
| 0 | 7 | 0 | 4 | -21.58 | 304.96 | -18.16 | 146.35 | 0.5251 | -788.0 | -693.5 | |
| 3 | 32 | 2 | 19 | -20.56 | 304.75 | -18.37 | 144.85 | 0.5148 | 1085.7 | 732.7 | |
| 0 | 3 | 0 | 2 | -21.94 | 304.21 | -18.91 | 145.71 | 0.5356 | -511.0 | -398.1 | |
| 10 | 35 | 6 | 20 | -21.21 | 304.27 | -18.85 | 144.95 | 0.5266 | -103.0 | 203.5 | |
| 0 | 4 | 0 | 2 | -23.12 | 303.78 | -19.34 | 146.43 | 0.5530 | 479.0 | 300.1 | |
| 0 | 4 | 0 | 2 | -21.78 | 303.75 | -19.37 | 144.90 | 0.5376 | 109.0 | 122.0 | |
| 0 | 6 | 0 | 4 | -20.50 | 303.84 | -19.28 | 143.50 | 0.5220 | 971.0 | 827.3 | |
| 3 | 43 | 2 | 26 | -22.74 | 303.44 | -19.68 | 145.55 | 0.5514 | 997.7 | 602.3 | |
| 3 | -31 | 2 | -31 | -22.87 | 303.19 | -19.93 | 145.38 | 0.5550 | 526.4 | 999999 | |
| 0 | 21 | 0 | 13 | -23.53 | 302.96 | -20.16 | 145.80 | 0.5645 | -501.0 | -579.8 | |
| 3 | -31 | 2 | -31 | -22.28 | 302.84 | -20.28 | 144.25 | 0.5511 | -137.5 | 999999 | |
| 0 | 7 | 0 | 4 | -22.44 | 301.79 | -21.33 | 143.08 | 0.5620 | -596.0 | -480.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
