SOHO MDI 2000-10-31 11:11:32 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 91 | 611 | 58 | 375 | 2.48 | 271.69 | -36.50 | 91.71 | 0.5966 | 1415.3 | 527.3 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2000-10-31 11:11:32 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 34 | 598 | 21 | 367 | 2.33 | 272.62 | -35.57 | 92.08 | 0.5838 | 1761.0 | 537.6 | |
| 2 | -1 | 2 | -1 | 1.96 | 272.15 | -36.03 | 92.65 | 0.5908 | 1202.9 | 999999 | |
| 4 | -1 | 3 | -1 | 1.76 | 272.01 | -36.17 | 92.96 | 0.5930 | 1142.4 | 999999 | |
| 5 | -1 | 3 | -1 | 3.45 | 271.77 | -36.42 | 90.09 | 0.5949 | 1241.7 | 999999 | |
| 6 | -1 | 4 | -1 | 1.94 | 271.67 | -36.51 | 92.62 | 0.5975 | 1155.8 | 999999 | |
| 29 | -1 | 18 | -1 | 2.58 | 271.32 | -36.87 | 91.50 | 0.6018 | 1384.3 | 999999 | |
| 4 | -1 | 2 | -1 | 3.35 | 271.24 | -36.95 | 90.22 | 0.6023 | 1090.3 | 999999 | |
| 7 | -1 | 5 | -1 | 2.99 | 270.96 | -37.22 | 90.79 | 0.6064 | 968.2 | 999999 | |
| 0 | 4 | 0 | 2 | 2.78 | 266.62 | -41.57 | 90.72 | 0.6651 | 372.0 | 348.1 | |
| 0 | 3 | 0 | 2 | 2.06 | 266.18 | -42.01 | 91.75 | 0.6715 | 660.0 | 459.0 | |
| 0 | 2 | 0 | 1 | -2.72 | 262.78 | -45.41 | 98.04 | 0.7208 | 155.0 | 178.3 | |
| 0 | 4 | 0 | 3 | 3.66 | 260.00 | -48.18 | 88.98 | 0.7462 | -609.0 | -451.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
