SOHO MDI 2000-11-04 01:35:32 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 57 | 402 | 31 | 215 | -9.64 | 279.06 | 18.31 | 232.80 | 0.3912 | -1758.7 | -531.0 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2000-11-04 01:35:32 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0 | 6 | 0 | 3 | -6.08 | 280.46 | 19.72 | 243.06 | 0.3779 | -606.0 | -511.3 | |
| 46 | 362 | 25 | 195 | -9.29 | 280.04 | 19.29 | 235.33 | 0.3982 | -1944.9 | -614.7 | |
| 11 | -2 | 6 | -2 | -9.81 | 278.79 | 18.05 | 232.42 | 0.3869 | -1455.7 | 999999 | |
| 0 | 4 | 0 | 2 | -14.07 | 275.74 | 14.99 | 219.21 | 0.3985 | -753.0 | -579.2 | |
| 0 | 4 | 0 | 2 | -14.82 | 274.68 | 13.93 | 216.01 | 0.3976 | -577.0 | -431.3 | |
| 0 | 5 | 0 | 3 | -11.85 | 269.65 | 8.90 | 209.13 | 0.3126 | 880.0 | 634.0 | |
| 0 | 6 | 0 | 3 | -13.45 | 269.63 | 8.88 | 206.68 | 0.3358 | 883.0 | 746.6 | |
| 0 | 6 | 0 | 3 | -11.88 | 269.21 | 8.47 | 207.87 | 0.3096 | 880.0 | 603.9 | |
| 0 | 9 | 0 | 4 | -13.63 | 267.32 | 6.57 | 200.21 | 0.3233 | 1171.0 | 826.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
