SOHO MDI 2000-11-04 20:47:32 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 47 | 324 | 28 | 189 | -9.85 | 278.23 | 28.02 | 242.98 | 0.5209 | -1476.8 | -430.3 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2000-11-04 20:47:32 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 37 | 240 | 22 | 141 | -9.32 | 280.16 | 29.95 | 245.98 | 0.5415 | -1661.4 | -581.0 | |
| 10 | 26 | 6 | 15 | -9.75 | 278.85 | 28.65 | 244.28 | 0.5266 | -1230.6 | -912.4 | |
| 0 | 8 | 0 | 5 | -10.13 | 278.53 | 28.33 | 243.36 | 0.5247 | -544.0 | -402.9 | |
| 0 | 5 | 0 | 3 | -13.26 | 276.61 | 26.41 | 236.36 | 0.5220 | -572.0 | -492.5 | |
| 0 | 5 | 0 | 3 | -13.43 | 269.29 | 19.08 | 227.24 | 0.4349 | 793.0 | 643.8 | |
| 0 | 7 | 0 | 4 | -11.87 | 267.80 | 17.59 | 227.77 | 0.4012 | 638.0 | 570.9 | |
| 0 | 24 | 0 | 13 | -13.66 | 266.93 | 16.73 | 223.11 | 0.4110 | 971.0 | 818.3 | |
| 0 | 4 | 0 | 2 | -3.70 | 265.92 | 15.71 | 244.40 | 0.3010 | 533.0 | 469.5 | |
| 0 | 5 | 0 | 3 | -12.71 | 265.55 | 15.35 | 222.35 | 0.3849 | 759.0 | 661.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
