SOHO MDI 2000-11-05 10:28:32 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 7 | 160 | 4 | 89 | 9.85 | 269.40 | 26.71 | 284.87 | 0.4596 | 453.6 | 388.9 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2000-11-05 10:28:32 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0 | 5 | 0 | 3 | 5.84 | 277.55 | 34.85 | 274.73 | 0.5727 | 442.0 | 531.7 | |
| 0 | 4 | 0 | 2 | 6.32 | 275.16 | 32.46 | 275.76 | 0.5384 | 669.0 | 660.3 | |
| 0 | 4 | 0 | 2 | 8.52 | 273.83 | 31.13 | 280.13 | 0.5215 | 691.0 | 639.3 | |
| 0 | 3 | 0 | 2 | 10.24 | 273.36 | 30.67 | 283.55 | 0.5184 | 614.0 | 590.6 | |
| 0 | 3 | 0 | 2 | 7.86 | 272.91 | 30.22 | 279.04 | 0.5069 | 647.0 | 594.8 | |
| 0 | 5 | 0 | 3 | 11.36 | 272.35 | 29.66 | 286.07 | 0.5069 | 473.0 | 547.4 | |
| 0 | 6 | 0 | 4 | 13.51 | 272.35 | 29.66 | 290.16 | 0.5146 | 633.0 | 380.5 | |
| 0 | 6 | 0 | 4 | 9.83 | 271.92 | 29.23 | 283.20 | 0.4962 | -301.0 | -224.7 | |
| 0 | 9 | 0 | 5 | 9.06 | 271.72 | 29.02 | 281.73 | 0.4913 | 828.0 | 882.1 | |
| 5 | 12 | 3 | 7 | 10.00 | 271.22 | 28.53 | 283.80 | 0.4863 | 930.8 | 514.3 | |
| 0 | 5 | 0 | 3 | 10.55 | 269.82 | 27.12 | 285.50 | 0.4670 | 596.0 | 503.8 | |
| 2 | 33 | 1 | 18 | 9.24 | 269.61 | 26.92 | 282.79 | 0.4601 | -168.0 | 642.7 | |
| 0 | 6 | 0 | 3 | 10.29 | 269.44 | 26.74 | 285.11 | 0.4606 | 883.0 | 768.4 | |
| 0 | 5 | 0 | 3 | 9.10 | 269.16 | 26.47 | 282.65 | 0.4529 | 630.0 | 539.4 | |
| 0 | 7 | 0 | 4 | 10.65 | 268.99 | 26.30 | 286.09 | 0.4551 | 593.0 | 390.7 | |
| 0 | 8 | 0 | 4 | 9.38 | 268.84 | 26.14 | 283.39 | 0.4487 | 450.0 | 380.0 | |
| 0 | 8 | 0 | 4 | 9.73 | 268.69 | 26.00 | 284.22 | 0.4476 | 718.0 | 626.4 | |
| 0 | 5 | 0 | 3 | 8.95 | 267.42 | 24.73 | 283.00 | 0.4259 | 608.0 | 596.0 | |
| 0 | 6 | 0 | 3 | 12.19 | 265.12 | 22.43 | 291.97 | 0.4039 | -745.0 | -684.9 | |
| 0 | 5 | 0 | 2 | 7.85 | 263.72 | 21.03 | 281.85 | 0.3648 | -639.0 | -512.3 | |
| 0 | 4 | 0 | 2 | 8.81 | 262.36 | 19.67 | 285.25 | 0.3463 | 201.0 | 138.1 | |
| 0 | 3 | 0 | 2 | 12.79 | 261.05 | 18.35 | 297.39 | 0.3474 | -690.0 | -547.2 | |
| 0 | 4 | 0 | 2 | 12.90 | 259.44 | 16.75 | 299.74 | 0.3250 | -704.0 | -661.0 | |
| 0 | 4 | 0 | 2 | 13.74 | 253.51 | 10.81 | 313.55 | 0.2526 | -668.0 | -693.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
