SOHO MDI 2001-02-02 17:35:32 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 73 | 524 | 50 | 361 | 24.97 | 114.20 | -32.00 | 43.63 | 0.6958 | 488.8 | 184.7 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2001-02-02 17:35:32 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 32 | 210 | 21 | 138 | 23.66 | 117.44 | -28.77 | 42.29 | 0.6574 | 1446.9 | 663.0 | |
| 10 | 37 | 7 | 25 | 24.97 | 116.23 | -29.97 | 41.98 | 0.6795 | 824.8 | 227.5 | |
| 2 | 9 | 1 | 6 | 23.67 | 116.42 | -29.78 | 43.23 | 0.6665 | 830.0 | 711.7 | |
| 0 | 19 | 0 | 12 | 23.70 | 116.03 | -30.17 | 43.56 | 0.6702 | 787.0 | 754.6 | |
| 0 | 4 | 0 | 2 | 24.92 | 115.56 | -30.65 | 42.64 | 0.6848 | 315.0 | 282.4 | |
| 0 | 11 | 0 | 7 | 23.86 | 115.55 | -30.65 | 43.82 | 0.6758 | 737.0 | 693.6 | |
| 0 | 3 | 0 | 2 | 23.73 | 114.65 | -31.55 | 44.75 | 0.6828 | 537.0 | 444.4 | |
| 0 | 5 | 0 | 4 | 26.60 | 113.70 | -32.50 | 42.43 | 0.7144 | -838.0 | -702.1 | |
| 5 | 29 | 4 | 20 | 24.55 | 114.28 | -31.93 | 44.16 | 0.6929 | 732.6 | 359.4 | |
| 0 | 3 | 0 | 2 | 23.58 | 114.25 | -31.95 | 45.26 | 0.6852 | 492.0 | 459.6 | |
| 0 | 8 | 0 | 6 | 26.42 | 113.00 | -33.21 | 43.21 | 0.7188 | -618.0 | -322.0 | |
| 0 | 11 | 0 | 8 | 25.56 | 113.12 | -33.09 | 44.03 | 0.7110 | -369.0 | -214.5 | |
| 0 | 7 | 0 | 5 | 24.73 | 112.82 | -33.39 | 45.18 | 0.7071 | 459.0 | 440.5 | |
| 0 | 5 | 0 | 4 | 23.76 | 112.75 | -33.45 | 46.31 | 0.7001 | 606.0 | 471.3 | |
| 0 | 7 | 0 | 5 | 24.67 | 112.43 | -33.77 | 45.56 | 0.7099 | 357.0 | 244.7 | |
| 0 | 4 | 0 | 3 | 25.10 | 111.94 | -34.27 | 45.48 | 0.7175 | 225.0 | 135.9 | |
| 0 | 9 | 0 | 7 | 28.80 | 110.18 | -36.02 | 42.91 | 0.7594 | -690.0 | -715.8 | |
| 3 | 9 | 2 | 6 | 27.62 | 110.58 | -35.62 | 43.82 | 0.7476 | 216.1 | 107.4 | |
| 9 | 23 | 7 | 17 | 26.74 | 110.86 | -35.35 | 44.54 | 0.7389 | -1053.9 | -803.5 | |
| 2 | 59 | 1 | 43 | 24.82 | 111.41 | -34.80 | 46.20 | 0.7200 | 319.0 | -450.1 | |
| 0 | 3 | 0 | 2 | 26.66 | 109.98 | -36.22 | 45.28 | 0.7456 | -635.0 | -627.8 | |
| 5 | -20 | 3 | -20 | 25.29 | 110.37 | -35.84 | 46.47 | 0.7325 | -1127.6 | 999999 | |
| 0 | 6 | 0 | 4 | 27.33 | 109.46 | -36.74 | 44.95 | 0.7546 | -606.0 | -525.3 | |
| 0 | 3 | 0 | 2 | 30.14 | 107.71 | -38.49 | 43.29 | 0.7872 | -417.0 | -362.1 | |
| 0 | 7 | 0 | 5 | 27.25 | 108.68 | -37.53 | 45.60 | 0.7603 | -705.0 | -614.7 | |
| 0 | 4 | 0 | 3 | 29.35 | 107.68 | -38.52 | 44.12 | 0.7822 | -452.0 | -403.4 | |
| 0 | 3 | 0 | 3 | 28.93 | 107.64 | -38.56 | 44.57 | 0.7798 | -534.0 | -471.4 | |
| 5 | 17 | 4 | 13 | 28.27 | 107.81 | -38.39 | 45.13 | 0.7741 | -754.8 | -630.1 | |
| 0 | 4 | 0 | 3 | 29.06 | 107.13 | -39.07 | 44.78 | 0.7845 | -183.0 | -177.9 | |
| 0 | 5 | 0 | 4 | 28.66 | 106.91 | -39.29 | 45.34 | 0.7836 | -465.0 | -409.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
