SOHO MDI 2002-04-07 01:35:33 UT
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 45 | 200 | 23 | 101 | -2.00 | 260.52 | 6.47 | 304.05 | 0.1360 | -315.3 | -148.0 | |
|
previous
or next observation for the same group /
back to the solar disc SOHO MDI 2002-04-07 01:35:33 UT |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 16 | 88 | 8 | 44 | -2.04 | 262.21 | 8.16 | 296.97 | 0.1600 | -1625.4 | -1066.7 | |
| 10 | -1 | 5 | -1 | -2.13 | 261.74 | 7.69 | 297.91 | 0.1521 | -1747.6 | 999999 | |
| 0 | 13 | 0 | 7 | -1.83 | 261.11 | 7.06 | 301.83 | 0.1453 | -547.0 | -291.1 | |
| 0 | 4 | 0 | 2 | -1.99 | 260.53 | 6.48 | 303.13 | 0.1353 | 530.0 | 301.4 | |
| 0 | 9 | 0 | 5 | -2.42 | 260.22 | 6.17 | 301.64 | 0.1266 | -552.0 | -226.5 | |
| 0 | 4 | 0 | 2 | -0.40 | 259.94 | 5.89 | 314.68 | 0.1449 | 862.0 | 697.3 | |
| 5 | 19 | 3 | 9 | -2.08 | 259.67 | 5.62 | 306.45 | 0.1221 | 1136.1 | 655.9 | |
| 0 | 3 | 0 | 2 | -0.09 | 259.59 | 5.53 | 317.93 | 0.1446 | 764.0 | 557.2 | |
| 0 | 10 | 0 | 5 | -2.00 | 259.20 | 5.15 | 309.38 | 0.1165 | 657.0 | 765.1 | |
| 4 | 16 | 2 | 8 | -1.93 | 258.65 | 4.60 | 313.07 | 0.1102 | 1313.0 | 931.3 | |
| 10 | 26 | 5 | 13 | -2.40 | 258.38 | 4.33 | 311.54 | 0.1012 | 1496.0 | 918.3 | |
| 0 | 8 | 0 | 4 | -1.35 | 258.34 | 4.29 | 318.72 | 0.1138 | 948.0 | 732.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
